ABB - Installation Products 54214UB - Copper Two-Hole Lug, 90 Degree Bend Standard Barrel, Peep Hole, Max 35kV, Wire Size 300 kcmil, 3/8 Inch Bolt Size, 1 Inch Hole Spacing, Tin Plated, Die Code 66, Die Color Code White
ABB - Installation Products

54214UB

UPC: 786210081700

Documents & Media
Specification SheetManufacturer Product Website

Contact for Pricing

Minimum Qty: 10

Multiplier: 10

*Contact for lower quantities*

Overview

The ABB 54214UB Copper Two-Hole Lug is a precision-engineered electrical connector designed for high-voltage applications up to 35kV. It features a 90-degree bend and a standard barrel with a peep hole for visual inspection of wire insertion and secure mechanical fastening. Constructed from high-conductivity copper, the lug ensures optimal electrical performance while the tin plating provides enhanced corrosion resistance, extending service life in harsh environments. The lug accommodates a maximum wire size of 300 kcmil and is compatible with a 3/8-inch bolt diameter for secure attachment to bus bars or other conductors. The 1-inch hole spacing aligns with standard mounting configurations, ensuring easy integration into existing systems. With a die code of 66 and a white color code, the 54214UB meets industry standards for identification and traceability. This lug is engineered for reliability in power distribution, transmission systems, and industrial machinery, where durable, high-current terminations are critical. Its design supports efficient heat dissipation and long-term electrical integrity, making it suitable for demanding applications in utility, renewable energy, and manufacturing sectors.
  • 90-degree bend design for optimized cable routing
  • Peep hole in standard barrel for visual inspection
  • Tin-plated copper construction for corrosion resistance
  • Supports 300 kcmil wire size with 3/8" bolt diameter
  • 1-inch hole spacing for standard mounting compatibility

Specifications

Cable Size
300 kcmil
Color
White
Connection Type
Two-Hole Lug, 90 Degree Bend
Connection Type
90 Degree Bend, Peep Hole
Connection Type
90 Degree Bend Standard Barrel with Peep Hole
Connection Type
Two-Hole Lug
Insulation
None
Material
Copper
Material
Copper, Tin Plated
Mounting Type
Bolt-On
Mounting Type
90 Degree Bend
Mounting Type
Bolted
Mounting Type
90 Degree Bend Standard Barrel
Mounting Type
Two-Hole Lug
Number Of Holes
2
Series
54214
Series
66
Series
54214UB
Size
300 kcmil
Size
300 kcmil, 3/8 Inch Bolt Size, 1 Inch Hole Spacing
Standard
UL E9809 / UL E9809
Standard
UL E9809
Stud Size
3/8 in
Type
Standard Barrel 90 Degree Bend
Voltage Rating
35 kV
Package Dimensions (L x W x H)
4 IN x 4 IN x 3 IN
Package Dimensions (L x W x H)
10.16 cm x 10.16 cm x 7.62 cm
Package Weight (Imperial)
0.200 L
Package Weight (Metric)
0.091 kg
