ABB - Installation Products 542070616B - Copper Two-Hole Lug, Standard Barrel -Bottom Stacking, Peep Hole, Max 35kV, Wire Size #2 AWG, 3/8 Inch Bolt Size, 1 Inch Hole Spacing, Tin Plated, Die Code 33, Die Color Code Brown
ABB - Installation Products

542070616B

UPC: 786210621654

Documents & Media
Manufacturer Product Website

Contact for Pricing

Minimum Qty: 25

Multiplier: 25

*Contact for lower quantities*

Overview

The ABB Copper Two-Hole Lug, SKU 542070616B, is a robust electrical termination component designed for reliable connections in high-voltage industrial applications. Manufactured by ABB - Installation Products, this lug is constructed from high-quality copper, ensuring excellent conductivity and durability. Its tin-plated finish provides superior corrosion resistance, extending the lifespan of the connection. Engineered for demanding environments, this lug features a standard barrel with a bottom stacking design, facilitating efficient and organized wiring layouts. The integrated peep hole allows for visual verification of conductor insertion, ensuring a secure and proper termination. Rated for a maximum voltage of 35 kV, this lug is suitable for power distribution systems, heavy machinery, and other critical electrical infrastructure where high voltage integrity is paramount. The lug accommodates wire sizes up to #2 AWG and utilizes a 3/8-inch bolt size for secure fastening. With a standard hole spacing of 1 inch, it offers compatibility with common mounting hardware. The die code 33 and brown color code provide clear identification and aid in inventory management. Originating from the US, this ABB lug exemplifies precision engineering and material quality for dependable electrical connections. Ideal for applications requiring secure, high-voltage terminations, this two-hole lug offers a practical and reliable solution for electrical engineers and maintenance professionals.
  • High-quality tin-plated copper construction for excellent conductivity and corrosion resistance.
  • Rated for a maximum voltage of 35 kV, suitable for high-voltage industrial applications.
  • Accommodates #2 AWG wire size with a 3/8-inch bolt size and 1-inch hole spacing.
  • Standard barrel with bottom stacking and peep hole for easy inspection and installation.
  • Manufactured by ABB - Installation Products, ensuring reliable performance and durability.

Specifications

Cable Size
2 AWG
Color
Brown
Connection Type
Bottom Stacking, Peep Hole
Connection Type
Two-Hole Lug
Insulation
None
Material
Copper
Material
Copper, Tin Plated
Mounting Type
3/8 Inch Bolt
Mounting Type
Bolt
Mounting Type
Bottom Stacking
Number Of Holes
2
Poles
2-hole
Series
542070616B
Size
#2 AWG
Size
#2 AWG, 3/8 Inch Bolt, 1 Inch Hole Spacing
Size
#2 AWG, 3/8 Inch Bolt Size, 1 Inch Hole Spacing
Standard
UL E9809 / UL E9809
Standard
UL E9809
Stud Size
3/8 in
Type
Standard Barrel - Bottom Stacking
Voltage Rating
35 kV
Package Dimensions (L x W x H)
3.25 IN x 2.75 IN x 2.25 IN
Package Dimensions (L x W x H)
8.255 cm x 6.985 cm x 5.715 cm
Package Weight (Imperial)
0.040 L
Package Weight (Metric)
0.018 kg
