ABB - Installation Products 54170UB - Copper One-Hole Lug, 90 Degree Standard Barrel, Peep Hole, Max 35kV, Wire Size 4/0 AWG, 1/2 Inch Bolt Size, Tin Plated, Die Code 54, Die Color Code Purple
ABB - Installation Products

54170UB

UPC: 786210640075

Documents & Media
Specification SheetManufacturer Product Website

Contact for Pricing

Minimum Qty: 10

Multiplier: 10

*Contact for lower quantities*

Overview

The ABB 54170UB Copper One-Hole Lug is a 90-degree standard barrel connector designed for secure high-voltage electrical connections. This lug is rated for a maximum of 35kV, making it suitable for demanding power applications. Constructed from tin-plated copper, it offers excellent resistance to corrosion and ensures optimal electrical conductivity. The lug is engineered to accommodate wire sizes up to 4/0 AWG, providing a versatile solution for various wiring requirements. It features a 1/2-inch bolt size, which facilitates a stable and reliable mechanical joint. The inclusion of a peep hole allows for visual confirmation of proper wire insertion, enhancing installation accuracy and safety. For efficient identification and management, the lug is marked with die code 54 and a corresponding purple die color code. This specific die code is crucial for ensuring correct crimping procedures. The ABB 54170UB is an ideal component for power distribution systems, industrial machinery, and electrical panels where dependable, high-voltage connections are paramount. Its compatibility with standard crimping tools utilizing die code 54 ensures seamless integration into existing electrical infrastructure and adherence to industrial safety and performance standards for high-voltage applications.
  • 90-degree standard barrel design for secure high-voltage connections
  • Tin-plated copper construction resists corrosion and ensures optimal conductivity
  • Rated for wire sizes up to 4/0 AWG and maximum 35kV
  • 1/2-inch bolt size for stable mechanical joint
  • Peep hole allows visual inspection of wire insertion
  • Purple die code (54) for quick identification during installation
  • Compatible with standard crimping tools using die code 54
  • Ideal for power distribution systems, industrial machinery, and electrical panels

Specifications

Cable Size
4/0 AWG
Color
Purple
Connection Type
90° Lug
Insulation
None
Material
Copper
Material
Tin-Plated Copper
Material
Copper, Tin Plated
Mounting Type
Bolt
Number Of Holes
1
Size
4/0 AWG
Size
4/0 AWG, 1/2 Inch Bolt Size
Standard
UL E9809
Standard
UL E9809 / UL E9809
Stud Size
1/2 in
Type
Standard Barrel 90 Degree Bend
Voltage Rating
35 kV
Package Dimensions (L x W x H)
3.25 IN x 2.75 IN x 2.25 IN
Package Dimensions (L x W x H)
8.255 cm x 6.985 cm x 5.715 cm
Package Weight (Imperial)
0.060 L
Package Weight (Metric)
0.027 kg
