Contact for Pricing
Minimum Qty: 10
Multiplier: 10
*Contact for lower quantities*
Overview
- High Voltage Rating: Designed for use in systems up to 35 kV.
- Premium Copper Construction: Ensures excellent conductivity and long-term reliability.
- Tin Plated Finish: Provides superior corrosion resistance.
- Standard Barrel with Peep Hole: Allows for visual inspection of conductor insertion.
- Wire and Bolt Compatibility: Accommodates 1/0 AWG wire and 5/16-inch bolts.
Specifications
Cable Size | 1/0 AWG |
Color | Pink |
Insulation | None |
Material | Copper |
Number Of Holes | 1 |
Standard | UL E9809 |
Standard | UL E9809 / UL E9809 |
Stud Size | 5/16 in |
Type | Standard Barrel |
Voltage Rating | 35 kV |
Package Dimensions (L x W x H) | 3.3 IN x 2.8 IN x 2.3 IN |
Package Dimensions (L x W x H) | 8.382 cm x 7.112 cm x 5.842 cm |
Package Weight (Imperial) | 0.050 L |
Package Weight (Metric) | 0.023 kg |
OD581
Mechanical Crimp Tool with 5/8 Inch Nose Die APPLICATIONS: Designed for use with wide range and H-Tap connectors. It has fiberglass handles and comes with "O" and "D" Nose Dies. It has an output of 4.5 tons.
CD6A
U-Type Compression Die - Pink 1/0 AWG Copper - 2 AWG Aluminum U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.
CD7
U-Type Compression Die - Black 2/0 AWG Copper U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.
E6-PS-D
Non-Insulated Parallel Splice Connector For Wire Range 6 For Circular Mil Range 20,800-33,100 Length .5 Diameter .365,Metallic
AS-K1-H6
Power Distribution Block (1) 2/0-14 AWG Primary (6) 4-14 AWG Secondary Power Distribution Blocks are made of high strength, high-conductivity aluminum alloy and are mounted in a high-strength glass-filled polyester base. Each block can stand alone or combine with other blocks to form a multi-block set.
E989NNJ-5-HD
Molded Junction Box, Length 4 Inch x Width 4 Inch x Depth 2 Inch, Material Polycarbonate, Color Gray
1SNK705010R0000
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.
1SNK705030R0000
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.
How to Install the 54153-TB Connector
This guide provides step-by-step instructions for installing the 54153-TB connector, ensuring a secure and reliable electrical connection.
Estimated time: 30m
Tools needed:
Wire strippers, Crimping tool, Multimeter
Supplies needed:
54153-TB connectors, Cable, Insulation tubing
- Prepare the cable
Strip the insulation from the cable to the specified length, ensuring not to nick the strands. Clean the cable end with a wire brush.
- Insert the cable into the connector
Insert the prepared cable end into the 54153-TB connector until it stops. Use the inspection peep hole to confirm that the cable is fully inserted.
- Crimp the connector
Place the connector in the crimping tool and compress it according to the specified markings. Ensure to apply the correct number of compressions as indicated in the installation table.
- Inspect and clean the connection
After crimping, remove any sharp edges or burrs from the connector to ensure a safe installation.
- Insulate the connection
Apply insulation to the crimped connector using the method specified in the installation table to protect against electrical hazards.
