UPC: 786210541280
Contact for Pricing
Overview
- Rated for up to 35kV and 1000 kcmil stranded copper conductors
- Tin-plated copper construction for corrosion resistance and high conductivity
- Peep hole for visual confirmation of full conductor insertion
- 5/8-inch bolt size with color-coded die index (Code 125) for tool compatibility
- UL Listed and CSA Certified; meets NEBS Level 3 and ABS standards
Specifications
Cable Size | 1000 kcmil |
Insulation | None |
Material | Copper |
Number Of Holes | 1 |
Standard | UL E9809 |
Standard | UL E9809 / UL E9809 |
Stud Size | 5/8 in |
Type | Standard Barrel |
Voltage Rating | 35 kV |
Package Dimensions (L x W x H) | 4 IN x 4 IN x 3 IN |
Package Dimensions (L x W x H) | 10.16 cm x 10.16 cm x 7.62 cm |
Package Weight (Imperial) | 0.800 L |
Package Weight (Metric) | 0.363 kg |
OD581
Mechanical Crimp Tool with 5/8 Inch Nose Die APPLICATIONS: Designed for use with wide range and H-Tap connectors. It has fiberglass handles and comes with "O" and "D" Nose Dies. It has an output of 4.5 tons.
CD6A
U-Type Compression Die - Pink 1/0 AWG Copper - 2 AWG Aluminum U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.
CD7
U-Type Compression Die - Black 2/0 AWG Copper U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.
E6-PS-D
Non-Insulated Parallel Splice Connector For Wire Range 6 For Circular Mil Range 20,800-33,100 Length .5 Diameter .365,Metallic
AS-K1-H6
Power Distribution Block (1) 2/0-14 AWG Primary (6) 4-14 AWG Secondary Power Distribution Blocks are made of high strength, high-conductivity aluminum alloy and are mounted in a high-strength glass-filled polyester base. Each block can stand alone or combine with other blocks to form a multi-block set.
E989NNJ-5-HD
Molded Junction Box, Length 4 Inch x Width 4 Inch x Depth 2 Inch, Material Polycarbonate, Color Gray
1SNK705010R0000
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.
1SNK705030R0000
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.
How to Install the 54128 Connector
This guide provides step-by-step instructions for installing the 54128 connector, ensuring proper crimping and insulation for electrical connections.
Estimated time: 30m
Tools needed:
Wire strippers, Crimping tool, Multimeter
Supplies needed:
54128 connector, Cable, Insulation materials (adhesive pad or shrink tubing)
- Prepare the cable
Strip the insulation from the cable to the specified length, ensuring not to nick the strands. Clean the cable end with a wire brush.
- Insert the cable into the connector
Insert the prepared cable into the 54128 connector until it stops. Use the inspection peep hole to confirm that the cable is fully inserted.
- Crimp the connector
Place the connector in the crimping tool and compress it according to the markings, ensuring to follow the specified number of compressions for the connector type.
- Remove sharp edges
After crimping, carefully remove any sharp edges, flash, or burrs from the connector to ensure safety.
- Insulate the connection
Apply insulation using either an adhesive pad or shrink tubing as specified for the cable size to protect the connection.
- Verify the installation
Use a multimeter to check the connection for continuity and ensure that there are no shorts or open circuits.
