Contact for Pricing
Minimum Qty: 6
Multiplier: 6
*Contact for lower quantities*
Overview
- Tin-plated copper construction for corrosion resistance
- Standard barrel with peep hole for visual inspection
- Rated for maximum 35kV applications
- Accommodates wire sizes up to 750 kcmil
- 5/8 inch bolt size for secure termination
Specifications
Cable Size | 750 kcmil |
Color | Black |
Connection Type | Bolted |
Connection Type | One-Hole Lug |
Insulation | None |
Material | Copper |
Material | Copper, Tin Plated |
Material | Tin-Plated Copper |
Mounting Type | Bolted |
Mounting Type | Standard Barrel with Peep Hole |
Mounting Type | One-Hole Lug |
Number Of Holes | 1 |
Series | 106 |
Series | 54123 |
Size | 750 kcmil |
Size | 750 kcmil, 5/8 Inch Bolt Size |
Size | 750 kcmil, 5/8" bolt |
Standard | UL E9809 / UL E9809 |
Standard | UL E9809 |
Stud Size | 5/8 in |
Type | Standard Barrel |
Voltage Rating | 35 kV |
Package Dimensions (L x W x H) | 4 IN x 4 IN x 3 IN |
Package Dimensions (L x W x H) | 10.16 cm x 10.16 cm x 7.62 cm |
Package Weight (Imperial) | 0.620 L |
Package Weight (Metric) | 0.281 kg |
OD581
Mechanical Crimp Tool with 5/8 Inch Nose Die APPLICATIONS: Designed for use with wide range and H-Tap connectors. It has fiberglass handles and comes with "O" and "D" Nose Dies. It has an output of 4.5 tons.
CD6A
U-Type Compression Die - Pink 1/0 AWG Copper - 2 AWG Aluminum U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.
CD7
U-Type Compression Die - Black 2/0 AWG Copper U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.
E6-PS-D
Non-Insulated Parallel Splice Connector For Wire Range 6 For Circular Mil Range 20,800-33,100 Length .5 Diameter .365,Metallic
AS-K1-H6
Power Distribution Block (1) 2/0-14 AWG Primary (6) 4-14 AWG Secondary Power Distribution Blocks are made of high strength, high-conductivity aluminum alloy and are mounted in a high-strength glass-filled polyester base. Each block can stand alone or combine with other blocks to form a multi-block set.
E989NNJ-5-HD
Molded Junction Box, Length 4 Inch x Width 4 Inch x Depth 2 Inch, Material Polycarbonate, Color Gray
1SNK705010R0000
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.
1SNK705030R0000
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.
Frequently Asked Questions
What material is used in this product?
The product is made of high conductivity copper.
What is the finish of the product?
The product has a tin-plated finish.
What is the wire size compatibility?
The product is compatible with wire sizes 1600/24 and 750 MCM.
What are the dimensions of the product?
All dimensions are for reference only and are not specified in detail.
Are there any safety warnings for this product?
The document does not specify any safety warnings or precautions.
How to Install the 54123-TB Connector
This guide provides step-by-step instructions for installing the 54123-TB connector, ensuring proper crimping and insulation for reliable electrical connections.
Estimated time: 30m
Tools needed:
Wire strippers, Crimping tool, Multimeter
Supplies needed:
Connector 54123-TB, Adhesive pad, Shrink tubing, Cable
- Prepare the cable
Strip the insulation from the cable to the specified length. Avoid nicking the strands to prevent breakage.
- Insert the cable into the connector
Clean the cable end and insert it into the 54123-TB connector until it stops. Use the inspection peep hole to verify that the cable is fully inserted.
- Crimp the connector
Place the connector in the crimping tool and compress it according to the specified markings. Ensure to follow the correct number of compressions as indicated for the connector type.
- Remove sharp edges
After crimping, carefully remove any sharp edges, flash, or burrs from the connector to ensure safety and proper insulation.
- Insulate the connection
Use the appropriate insulation method as specified. Apply the adhesive pad or shrink tubing to protect the connection.
- Verify the connection
Use a multimeter to check the continuity and ensure that the connection is secure and functioning properly.
