UPC: 786210816258
Contact for Pricing
Minimum Qty: 25
Multiplier: 25
*Contact for lower quantities*
Overview
- 1-inch steel locknut with integrated sealing function
- Case-hardened for enhanced durability and resistance to slipping
- Compatible with 1-inch conduit sizes and straight pipe threads (NPS)
- UL-listed (UL File No. E-23018) and CSA-certified (LR-2884, LR-4484)
- Conforms to U.L. 514B, CSA C22.2 No. 18, and NEMA FB1 standards
Specifications
Application | Provides Positive Seal Against Water and Oil |
Material of Construction | Steel |
Size | 1 Inch |
Standard | UL E23018, CSA |
Thread Size | 1 inch |
Type | Locknuts |
Package Dimensions (L x W x H) | 4 IN x 4 IN x 3 IN |
Package Dimensions (L x W x H) | 10.16 cm x 10.16 cm x 7.62 cm |
Package Weight (Imperial) | 0.0400 L |
Package Weight (Metric) | 0.0180 kg |
How to Install the Thomas & Betts 143SL Sealing Locknut
This guide provides instructions for properly installing the Thomas & Betts 143SL Sealing Locknut to create a watertight or raintight grounded conduit connection, suitable for wet locations.
Estimated time: 5m
Tools needed:
Wrench
Supplies needed:
Thomas & Betts 143SL Sealing Locknut, Conduit, Enclosure, Rigid conduit locknut or bushing
- Thread Sealing Locknut onto Conduit
Thread the sealing locknut onto the conduit. Continue threading until the locknut reaches the end of the conduit's thread.
- Insert Conduit into Enclosure
Insert the conduit, with the sealing locknut positioned on the outside, into the designated entry point of the enclosure.
- Secure and Tighten Assembly
Install a rigid conduit locknut or a bushing on the inside of the enclosure. Tighten the entire assembly firmly to ensure a secure seal and proper ground connection.
