ABB - Electrification
X50-B4-48-XD
Contact for Pricing
Overview
- Heavy-duty class 30 starts for 50HP/68A loads and normal duty class 10 starts for 60HP/80A loads.
- Integrated AC-3 emergency bypass for uninterrupted operation during critical failures.
- NEMA Type 4 enclosure with conformal-coated electronics for harsh environments.
- Detachable IP66 keypad with large graphical display and 17 languages for intuitive control.
- Includes door-mounted pilot devices, TMAX XT breakers, and multiple electrical protection options.
- Detachable IP66-rated keypad with 17 languages and customizable display
- Built-in torque control and jogging functions for pumps, conveyors, and cranes
- Door-mounted pilot devices: H/O/A switch, start/stop buttons, pilot lights, emergency bypass controls
- Integrated TMAX XT breakers with circuit breaker or fused disconnect options
- Operational voltage: 208–600V AC, current range: 30–1250A
Specifications
Connection Type | Screw Terminal |
Current Rating | 80 A |
Enclosure | NEMA 4 |
Frequency | 60 Hz |
Ip Rating | Type 4 |
Material | Metal |
Mounting Type | Enclosed |
Nema Rating | Type 4 |
Series | PSTX Extreme Duty |
Size | Enclosed |
Special Features | The PSTX offers complete motor protection in only one unit and is able to handle both load and network irregularities. PT-100, earth fault protection and over/under voltage protectionalong with many other functions keep your motor safer than ever.It offers three types of current limit: standard, dual and ramp. This gives you full control of your motor during start. It also allows you to use your motor in weaker networks.The bypass is built in and saving you time during installation and space in your panel.The PSTX features many application enhancingfeatures, including torque control: the mostefficient way to start and stop pumps. The pumpcleaning feature can reverse pump flow and cleanout pipes, securing uptime of your pump system. Main benefits • Secure motor reliability• Improve installation efficiency• Increase application productivity.Main features • Three-phase controlled• Operational voltage: 440 to 480 V AC• Wide rated control supply voltage: 100-250 V, 50/60 Hz• Rated operational current: 15…1250 A• Coated circuit boards• Torque control for excellent control of pumpsAdditional normal/heavy duty features • Circuit Breaker or Fuses• Door Mounted Keypad• Start Pushbutton• Stop Pushbutton• Hand-Off-Auto selector switch• Power On Pilot Light• Run Pilot Light• Fault Pilot LightAdditional extreme duty features • Circuit Breaker or Fuses• Door Mounted Keypad• Emergency Bypass• Start Pushbutton• Stop Pushbutton• Hand-Off-Auto selector switch• Normal-E-Bypass selector switch• E- Bypass Start Pushbutton• E-Bypass Stop Pushbutton• Power On Pilot Light• Run Pilot Light• Fault Pilot Light• E-Bypass Pilot Light |
Voltage Rating | 480 VAC |
Voltage Rating | 480 V |
Package Dimensions (L x W x H) | 20 IN x 12 IN x 24 IN |
Package Dimensions (L x W x H) | 50.8 cm x 30.48 cm x 60.96 cm |
Package Weight (Imperial) | 200.000 L |
Package Weight (Metric) | 90.720 kg |
Frequently Asked Questions
What is the SSCR rating for the ABB PSTX X50-B4-48-XD?
The ABB PSTX Extreme Duty Enclosed Softstarter X50-B4-48-XD has a Short Circuit Current Rating (SSCR) of 65kA at 480V.
What types of motor starts does this softstarter support?
This softstarter supports heavy-duty class 30 starts for 50HP/68A loads and normal duty class 10 starts for 60HP/80A loads.
What is the enclosure rating for the X50-B4-48-XD?
The ABB PSTX X50-B4-48-XD features a NEMA Type 4 enclosure, providing protection against dust, moisture, and corrosive atmospheres.
Does the X50-B4-48-XD include an emergency bypass feature?
Yes, the X50-B4-48-XD includes an integrated AC-3 emergency bypass, allowing motors to continue running during equipment failure.
What are the dimensions of the ABB PSTX X50-B4-48-XD?
The dimensions of the ABB PSTX Extreme Duty Enclosed Softstarter X50-B4-48-XD are 447 mm (Height) x 900 mm (Width) x 447 mm (Depth).
What certifications does the PSTX X50-B4-48-XD have?
The ABB PSTX Extreme Duty Enclosed Softstarter X50-B4-48-XD is UL 508A and CSA C22.2 No. 286 certified.
What motor control features are included on the keypad?
The detachable keypad features a large graphical display, 17 pre-installed languages, customizable home screens, torque control, and jog functions.
