ABB - Electrification X150-B4-48-XD - PSTX extreme duty enclosed softstarters are the ultimate softstarting solution. Includes all features of the PSTX normal duty, sized for heavy duty applications, plus an AC-3 emergency bypass. Both the PSTX softstarter and TMAX XT breakers are utilized. Door mounted pilot devices include PSTX keypad, hand-off-auto selector switch, start and stop pushbuttons, power on pilot light, run pilot light, fault pilot light, normal/emergency bypass selector switch, emergency bypass start and stop pushbuttons and emergency bypass pilot light. Good for Normal Duty class 10 starts for 200HP/248A, heavy duty class 30 starts for 150HP/192A, SSCR rating of 65kA, 480V and type 4 enclosure.
ABB - Electrification

X150-B4-48-XD

Contact for Pricing

Overview

The ABB PSTX Extreme Duty Enclosed Softstarter (SKU: X150-B4-48-XD) is the ultimate softstarting solution for heavy-duty industrial applications. This unit integrates the full PSTX softstarter feature set with an AC-3 emergency bypass, ensuring operational continuity during equipment failure and allowing motors to run until scheduled maintenance. Designed for 480V three-phase systems, it supports heavy-duty Class 30 starts for 150HP (192A) motors and normal duty Class 10 starts for 200HP (248A) motors. The integrated bypass contactor engages at full speed, minimizing heat generation and extending product lifespan. The robust Type 4 enclosure offers comprehensive environmental protection. The door-mounted pilot devices include a PSTX keypad with a graphical LCD display, Hand-Off-Auto selector switch, Start and Stop pushbuttons, Power On pilot light, Run pilot light, and Fault pilot light. For bypass control, a Normal/Emergency bypass selector switch, Emergency bypass Start and Stop pushbuttons, and an Emergency bypass pilot light are also provided. With an SSCR rating of 65kA, this enclosed softstarter ensures safety and reliability. Key features include advanced torque control for precise pump starts, a pump cleaning functionality to reverse flow and clear pipes, and overload protection up to Class 10. Coated circuit boards and a thermostat-controlled cooling system enhance durability in harsh conditions. Certified to UL 508A and CSA C22.2 No. 286, this turnkey solution offers quick installation with pre-assembled components. Dimensions are 447 mm H x 900 mm W x 447 mm D. The PSTX offers three types of current limit: standard, dual, and ramp, providing full motor control during start-up, even in weaker networks. The HMI supports multiple languages including English, Spanish, French, and German, streamlining setup and operation. The PSTX enclosed softstarter provides secure motor reliability, improves installation efficiency, and increases application productivity.
  • Extreme duty enclosed softstarter with AC-3 emergency bypass for operational continuity
  • Supports heavy-duty Class 30 starts (150HP/192A) and normal duty Class 10 starts (200HP/248A) at 480V
  • Robust Type 4 enclosure with door-mounted pilot devices for comprehensive control and status indication
  • 65kA SSCR rating for enhanced safety and reliability
  • Features torque control, pump cleaning, and overload protection up to Class 10

Specifications

Color
Blue
Connection Type
Screw Terminal (implied by industrial standard)
Current Rating
248 A
Current Rating
192 A (heavy duty) / 248 A (normal duty)
Enclosure
NEMA 4
Frequency
60 Hz (implied by industrial standard)
Ip Rating
IP66/IP67
Ip Rating
Type 4 (equivalent to IP66)
Material
Poly
Mounting Type
Enclosed Cabinet
Nema Rating
Type 4
Poles
3
Series
PSTX Extreme Duty
Size
Size 1
Size
Not explicitly stated
Special Features
The PSTX offers complete motor protection in only one unit and is able to handle both load and network irregularities. PT-100, earth fault protection and over/under voltage protectionalong with many other functions keep your motor safer than ever.It offers three types of current limit: standard, dual and ramp. This gives you full control of your motor during start. It also allows you to use your motor in weaker networks.The bypass is built in and saving you time during installation and space in your panel.The PSTX features many application enhancingfeatures, including torque control: the mostefficient way to start and stop pumps. The pumpcleaning feature can reverse pump flow and cleanout pipes, securing uptime of your pump system. Main benefits • Secure motor reliability• Improve installation efficiency• Increase application productivity.Main features • Three-phase controlled• Operational voltage: 440 to 480 V AC• Wide rated control supply voltage: 100-250 V, 50/60 Hz• Rated operational current: 15…1250 A• Coated circuit boards• Torque control for excellent control of pumpsAdditional normal/heavy duty features • Circuit Breaker or Fuses• Door Mounted Keypad• Start Pushbutton• Stop Pushbutton• Hand-Off-Auto selector switch• Power On Pilot Light• Run Pilot Light• Fault Pilot LightAdditional extreme duty features • Circuit Breaker or Fuses• Door Mounted Keypad• Emergency Bypass• Start Pushbutton• Stop Pushbutton• Hand-Off-Auto selector switch• Normal-E-Bypass selector switch• E- Bypass Start Pushbutton• E-Bypass Stop Pushbutton• Power On Pilot Light• Run Pilot Light• Fault Pilot Light• E-Bypass Pilot Light
Voltage Rating
480 VAC
Voltage Rating
480 V
Package Dimensions (L x W x H)
36 IN x 16 IN x 48 IN
Package Dimensions (L x W x H)
91.44 cm x 40.64 cm x 121.92 cm
Package Weight (Imperial)
300.000 L
Package Weight (Metric)
136.080 kg
GMD-16M DC240V 3W 1b EXP (GMD16M-30-01-UD-3W-S-E)

1270040900

GMD-16M DC240V 3W 1b EXP (GMD16M-30-01-UD-3W-S-E)
MT-63 34A 3D SCREW EXP (MT63-3D-34-S-E)

1311001000

MT-63 34A 3D SCREW EXP (MT63-3D-34-S-E)
One-hole, metric conductor, standard barrel with window lug, 4-6mm wire, M8 stud hole.

LCMA6-8-C

One-hole, metric conductor, standard barrel with window lug, 4-6mm wire, M8 stud hole.
Ground Lug

DNGL

Ground Lug
CONTACT BLOCK BU BLB-02

BLB-02

CONTACT BLOCK BU BLB-02
CONTACT BLOCK BU BFB-40

BFB-40

CONTACT BLOCK BU BFB-40

Frequently Asked Questions

Does this softstarter include an emergency bypass feature?

Yes, the PSTX extreme duty enclosed softstarter includes an AC-3 emergency bypass for operational continuity.

What certifications does the PSTX extreme duty enclosed softstarter have?

The PSTX extreme duty enclosed softstarter is certified to UL 508A and CSA C22.2 No. 286.

What is the operating voltage for the PSTX extreme duty softstarter?

The PSTX extreme duty enclosed softstarter operates on 208 to 600 V AC.

What is the SSCR rating of the ABB PSTX X150-B4-48-XD?

The ABB PSTX X150-B4-48-XD has an SSCR rating of 65kA.

What type of enclosure does the PSTX extreme duty softstarter use?

The PSTX extreme duty softstarter utilizes a Type 4 enclosure.

What are the dimensions of the PSTX enclosed softstarter?

The dimensions of the PSTX enclosed softstarter are 447 mm H x 900 mm W x 447 mm D.

What motor horsepower can this softstarter handle for heavy duty applications?

This softstarter is sized for heavy duty applications and can handle up to 150HP.

What motor horsepower can this softstarter handle for normal duty applications?

For normal duty applications, this softstarter can handle up to 200HP.

What is the rated operational current for this softstarter?

The rated operational current for this PSTX enclosed softstarter is 192A for heavy duty and 248A for normal duty.
