ABB - Electrification TSLUG12 - Kit accepts Cu/Al wire and requires the use of T-studs. UG12 Amps 1200 A
ABB - Electrification

TSLUG12

UPC: 783164098853

Contact for Pricing

Overview

The ABB TSLUG12 UG12 Kit (SKU: TSLUG12) is a field-installed lug solution for low-voltage power distribution, molded case circuit breakers, and industrial switchgear. This kit provides 12 lugs per unit, supporting up to 4 cables per pole with a wire range of 3/0 to 800 kcmil for both copper (Cu) and aluminum (Al) conductors. Each lug is rated for 1200A applications and requires the use of T-studs for secure mounting directly to the breaker. T-studs, available separately, can be rotated for vertical or horizontal bus connections, offering installation flexibility. The lugs are designed to accommodate both copper and aluminum wire types, ensuring compatibility with a wide range of conductor materials. Manufactured in the US, the TSLUG12 is UL 486A listed for safety and compliance. Its robust design ensures reliable conductivity and long-term durability in heavy-duty industrial environments. The UNSPSC code is 39121601.
  • 12 lugs per kit for 1200A applications
  • Accommodates copper (Cu) and aluminum (Al) conductors
  • Wire range: 3/0 to 800 kcmil
  • Supports up to 4 cables per pole
  • Requires T-studs for mounting (sold separately), offering rotational flexibility

Specifications

Amperage Rating
1200A
Application
Electrical distribution and Control
Connection
3/0-800 kcmil
Connection Type
T-stud
Current Rating
1200 A
Material
Copper/Aluminum
Series
UG12
Special Features
Kit accepts Cu/Al wire and requires the use of T-studs. UG12 Amps 1200 A
Type
Load Centers
Package Weight (Imperial)
98.436 L
Package Weight (Metric)
44.651 kg
