ABB - Electrification TS400RC - General Electric Service entrance. 200A main breaker metersocket load center. Closing cap for TSDA2440UC42.
ABB - Electrification

TS400RC

UPC: 783164400489

Contact for Pricing

Overview

The ABB TS400RC (SKU: TS400RC) is a robust 200A main breaker meter socket load center designed for General Electric service entrance applications. This unit provides reliable electrical distribution and metering for single-phase, 3-wire systems operating at 120/240V AC. It features a high interrupting capacity rating of 22kAIC, ensuring effective protection against overcurrents. The TS400RC is a single-main, ring-type load center with a surface mount NEMA 3R enclosure, making it suitable for outdoor use and compatible with both overhead and underground UL feeds. It offers 8 branch circuit breaker spaces and supports up to 16 branch circuit breaker circuits, providing ample capacity for electrical management. A removable closing cap is included for simplified maintenance, and hubs must be ordered separately. This load center is compatible with the TSDA2440UC42 and can accommodate a field-installed fifth jaw terminal (order code TJAW53, sold separately) in the 3 or 9 o'clock position. Constructed from G90 steel, the TS400RC is built for durability. The line wire range accommodates #8-250MCM Cu-Al on 3/8" studs. UL listed and approved by DTE utility, the TS400RC is an ideal choice for demanding service entrance applications requiring a dependable, high-capacity load center.
  • 200A Main Breaker Meter Socket Load Center
  • Designed for General Electric Service Entrance
  • 22kAIC Interrupting Capacity
  • NEMA 3R Outdoor Enclosure
  • 8 Branch Spaces, 16 Circuits

Specifications

Application
Electrical distribution and Control
Connection Type
Overhead/underground UL feed
Connection Type
Overhead and Underground UL Feed
Current Rating
200 A
Mounting Type
Surface Front
Poles
1P
Series
General Electric Service entrance
Series
TS400RC
Type
Renewal Parts
Package Dimensions (L x W x H)
33 IN x 10 IN x 6.25 IN
Package Dimensions (L x W x H)
83.82 cm x 25.4 cm x 15.875 cm
Package Weight (Imperial)
6.500 L
Package Weight (Metric)
2.948 kg
ReliaHome Meter Combo Load Center

TSMQ820CSCU

ReliaHome Meter Combo Load Center
PowerMark Gold Meter Socket Load Centers are an ideal option for residential applications. Additonally, PowerMark Gold Meter Socket Load Centers provide increased reliability and maximum circuit layout flexibility. All our PowerMark Gold Meter Socket Load Centers are built with high-quality materials for extended durability. Furthermore, their perfected design allows for an easy and fast installation. The TSMR820CFLFMG is a ringless, main breaker meter socket and features spaces for 8, 1" breakers, a 200A main ampere rating, Florida Meter Group Compatibility, and an outdoor suitable, surface enclosure.

TSMR820CSFLFMG

PowerMark Gold Meter Socket Load Centers are an ideal option for residential applications. Additonally, PowerMark Gold Meter Socket Load Centers provide increased reliability and maximum circuit layout flexibility. All our PowerMark Gold Meter Socket Load Centers are built with high-quality materials for extended durability. Furthermore, their perfected design allows for an easy and fast installation. The TSMR820CFLFMG is a ringless, main breaker meter socket and features spaces for 8, 1" breakers, a 200A main ampere rating, Florida Meter Group Compatibility, and an outdoor suitable, surface enclosure.
ReliaHome Meter Combo Load Center

TSMQ415CSCU

ReliaHome Meter Combo Load Center
PowerMark Gold Meter Socket Load Centers are an ideal option for residential applications. Additonally, PowerMark Gold Meter Socket Load Centers provide increased reliability and maximum circuit layout flexibility. All our PowerMark Gold Meter Socket Load Centers are built with high-quality materials for extended durability. Furthermore, their perfected design allows for an easy and fast installation. The TSMF415CSFL is a main breaker ,farm panel meter socket with a ring and features spaces for 8, 1" breakers, a 150A main ampere rating, a feed through lug, and an outdoor suitable, surface enclosure.

TSMF415CSFL

PowerMark Gold Meter Socket Load Centers are an ideal option for residential applications. Additonally, PowerMark Gold Meter Socket Load Centers provide increased reliability and maximum circuit layout flexibility. All our PowerMark Gold Meter Socket Load Centers are built with high-quality materials for extended durability. Furthermore, their perfected design allows for an easy and fast installation. The TSMF415CSFL is a main breaker ,farm panel meter socket with a ring and features spaces for 8, 1" breakers, a 150A main ampere rating, a feed through lug, and an outdoor suitable, surface enclosure.
PowerMark Gold Meter Socket Load Centers are an ideal option for residential applications. Additonally, PowerMark Gold Meter Socket Load Centers provide increased reliability and maximum circuit layout flexibility. All our PowerMark Gold Meter Socket Load Centers are built with high-quality materials for extended durability. Furthermore, their perfected design allows for an easy and fast installation. The TSM4020UWCU is a main breaker meter socket with a ring and features spaces for 40, 1" breakers, a 200A main ampere rating, a copper bus, and an outdoor suitable, wide surface enclosure.

TSM4020UWCU

PowerMark Gold Meter Socket Load Centers are an ideal option for residential applications. Additonally, PowerMark Gold Meter Socket Load Centers provide increased reliability and maximum circuit layout flexibility. All our PowerMark Gold Meter Socket Load Centers are built with high-quality materials for extended durability. Furthermore, their perfected design allows for an easy and fast installation. The TSM4020UWCU is a main breaker meter socket with a ring and features spaces for 40, 1" breakers, a 200A main ampere rating, a copper bus, and an outdoor suitable, wide surface enclosure.
PowerMark Gold Meter Socket Load Centers are an ideal option for residential applications. Additonally, PowerMark Gold Meter Socket Load Centers provide increased reliability and maximum circuit layout flexibility. All our PowerMark Gold Meter Socket Load Centers are built with high-quality materials for extended durability. Furthermore, their perfected design allows for an easy and fast installation. The TSM3220UWCU is a main breaker, wide body meter scoket with a ring and features a 200 A main ampere rating, a 22kAIC interrupting capacity rating, spcae for 32 , 1" breakers, a copper bus, and an outdoor suitable, surface enclosure.

TSM3220UWCU

PowerMark Gold Meter Socket Load Centers are an ideal option for residential applications. Additonally, PowerMark Gold Meter Socket Load Centers provide increased reliability and maximum circuit layout flexibility. All our PowerMark Gold Meter Socket Load Centers are built with high-quality materials for extended durability. Furthermore, their perfected design allows for an easy and fast installation. The TSM3220UWCU is a main breaker, wide body meter scoket with a ring and features a 200 A main ampere rating, a 22kAIC interrupting capacity rating, spcae for 32 , 1" breakers, a copper bus, and an outdoor suitable, surface enclosure.
ABB ReliaHome makes homes reliable, with ease. We designed our ReliaHome load centers to be installed as fast as possible – and reliable so your customers can leave a job with confidence. They work seamlessly with all our residential circuit breakers, optimizing your stock.

PCM4020

ABB ReliaHome makes homes reliable, with ease. We designed our ReliaHome load centers to be installed as fast as possible – and reliable so your customers can leave a job with confidence. They work seamlessly with all our residential circuit breakers, optimizing your stock.
200A Meter Socket Load Center 20 Circuit Ring Type OH/UG Surface Mount

TSM2020CSCUP

200A Meter Socket Load Center 20 Circuit Ring Type OH/UG Surface Mount
PowerMark Gold Meter Socket Load Centers are an ideal option for residential applications. Additonally, PowerMark Gold Meter Socket Load Centers provide increased reliability and maximum circuit layout flexibility. All our PowerMark Gold Meter Socket Load Centers are built with high-quality materials for extended durability. Furthermore, their perfected design allows for an easy and fast installation. The TSMR2020CSCU is a ringless, main breaker meter socket and features spaces for 20, 1" breakers, a 200A main ampere rating, a copper bus, a horn bypass, and an outdoor suitable, surface enclosure.

TSMR2020CSCU

PowerMark Gold Meter Socket Load Centers are an ideal option for residential applications. Additonally, PowerMark Gold Meter Socket Load Centers provide increased reliability and maximum circuit layout flexibility. All our PowerMark Gold Meter Socket Load Centers are built with high-quality materials for extended durability. Furthermore, their perfected design allows for an easy and fast installation. The TSMR2020CSCU is a ringless, main breaker meter socket and features spaces for 20, 1" breakers, a 200A main ampere rating, a copper bus, a horn bypass, and an outdoor suitable, surface enclosure.
PowerMark Gold Meter Socket Load Centers are an ideal option for residential applications. Additonally, PowerMark Gold Meter Socket Load Centers provide increased reliability and maximum circuit layout flexibility. All our PowerMark Gold Meter Socket Load Centers are built with high-quality materials for extended durability. Furthermore, their perfected design allows for an easy and fast installation.The TSM2420US42 is a main breaker meter socket with a ring and features spaces for 24, 1" breakers, a 200A main ampere rating, a full 42 circuit panel, and an outdoor suitable, surface enclosure.

TSM2420US42

PowerMark Gold Meter Socket Load Centers are an ideal option for residential applications. Additonally, PowerMark Gold Meter Socket Load Centers provide increased reliability and maximum circuit layout flexibility. All our PowerMark Gold Meter Socket Load Centers are built with high-quality materials for extended durability. Furthermore, their perfected design allows for an easy and fast installation.The TSM2420US42 is a main breaker meter socket with a ring and features spaces for 24, 1" breakers, a 200A main ampere rating, a full 42 circuit panel, and an outdoor suitable, surface enclosure.
ReliaHome Meter Combo Load Center

TSMQ1612CFCU

ReliaHome Meter Combo Load Center
ABB ReliaHome makes homes reliable, with ease. We designed our ReliaHome load centers to be installed as fast as possible – and reliable so your customers can leave a job with confidence. They work seamlessly with all our residential circuit breakers, optimizing your stock.

PCM3020

ABB ReliaHome makes homes reliable, with ease. We designed our ReliaHome load centers to be installed as fast as possible – and reliable so your customers can leave a job with confidence. They work seamlessly with all our residential circuit breakers, optimizing your stock.

Frequently Asked Questions

What is the interrupting rating of the ABB TS400RC?

The ABB TS400RC has an interrupting rating of 22kAIC.

What type of enclosure does the TS400RC have?

The TS400RC features a NEMA 3R enclosure, constructed from G90 steel.

Can a fifth jaw terminal be installed on the TS400RC?

Yes, the TS400RC accepts a field-installed fifth jaw terminal (order code TJAW53) in the 3 or 9 o'clock position.

Are hubs included with the ABB TS400RC?

No, hubs are not included with the TS400RC and must be ordered separately.

What is the line wire range for the TS400RC?

The line wire range for the TS400RC is #8-250MCM Cu-Al on 3/8" studs.

What is the amperage rating of the main breaker in the TS400RC?

The ABB TS400RC is a 200A main breaker meter load center.

How many branch circuit breaker spaces are available on the TS400RC?

The TS400RC provides 8 branch circuit breaker spaces.
