ABB - Electrification THQL1115AF2 - Arc fault breakers are designed to detect and prevent damages from arcing caused by damaged wire insulation or a frayed extension cord. All Q Line circuit breakers are one inch wide per pole, compact devices that feature: Quick-make / Quick-break mechanisms, common trip bars, and easy-to-spot trip indications to ensure safety and reliability. AF2 is a called a Combination breaker as it protects against arcs in both parallel and series and meets current NEC standards. The THQL1115AF2 breaker features arc-fault interrupting technology, 2 poles, an ampere rating of 15 A, an interrupting rating of 10kAIC, and a voltage rating of 120/240V.
ABB - Electrification

THQL1115AF2

UPC: 783164652802

Contact for Pricing

Overview

The ABB THQL1115AF2 is a 2-pole, 15 Ampere Q Line Combination Arc Fault Circuit Interrupter (AFCI) designed for enhanced electrical safety in residential and light commercial applications. This breaker meets current NEC standards and provides comprehensive protection against overloads, short circuits, parallel arcs, and series arcs. The THQL1115AF2 features ABB's reliable Quick-make/Quick-break mechanisms and common trip bars for simultaneous pole disconnection, ensuring safety under fault conditions. With a 10,000 AIC interrupting rating, it protects against up to 10,000 amps of available fault current. The compact 1-inch-per-pole design fits standard load centers, including ABB and GE load centers, meter combos, and modular metering systems. This breaker is rated for 120/240 Vac operation and is UL Listed to UL 489 standards. The THQL1115AF2 is ideal for protecting circuits in living rooms, bedrooms, kitchens, and other areas where arc faults are a concern, such as damaged wire insulation or frayed extension cords. Installation is straightforward, with plug-in neutral options for added flexibility. Arc fault breakers are designed to detect and prevent damages from arcing caused by damaged wire insulation or a frayed extension cord. All Q Line circuit breakers are one inch wide per pole, compact devices that feature: Quick-make / Quick-break mechanisms, common trip bars, and easy-to-spot trip indications to ensure safety and reliability. AF2 is a called a Combination breaker as it protects against arcs in both parallel and series and meets current NEC standards. The THQL1115AF2 breaker features arc-fault interrupting technology, 2 poles, an ampere rating of 15 A, an interrupting rating of 10kAIC, and a voltage rating of 120/240V.
  • 2-pole, 15 Ampere Combination Arc Fault Circuit Breaker (AFCI)
  • Protects against overloads, short circuits, parallel arcs, and series arcs
  • 10,000 AIC interrupting rating for enhanced fault protection
  • Compact 1-inch-per-pole design fits standard load centers
  • UL 489 listed, compliant with NEC standards

Specifications

Amperage Rating
15 A
Application
Thermal Magnetic
Connection Type
Screw Terminal
Current Rating
15 A
Frame
Q-Line
Interrupt Rating
10kA@120/240 Vac / 10kA@120 Vac
Interrupting Rating
10 kAIC
Load Rating
HACR / SWD
Mounting Type
1 inch per pole
Number Of Poles
1
Poles
2
Series
Q Line
Series
Q Line AF2
Special Features
Arc fault breakers are designed to detect and prevent damages from arcing caused by damaged wire insulation or a frayed extension cord. All Q Line circuit breakers are one inch wide per pole, compact devices that feature: Quick-make / Quick-break mechanisms, common trip bars, and easy-to-spot trip indications to ensure safety and reliability. AF2 is a called a Combination breaker as it protects against arcs in both parallel and series and meets current NEC standards. The THQL1115AF2 breaker features arc-fault interrupting technology, 2 poles, an ampere rating of 15 A, an interrupting rating of 10kAIC, and a voltage rating of 120/240V.
Standard
E11592
Trip Range
Non-Interchangeable
Trip Range, Maximum
Non-Interchangeable
Trip Range, Minimum
Non-Interchangeable
Trip Type
LI
Voltage Rating
120/240 V
Package Dimensions (L x W x H)
1.25 IN x 4.75 IN x 3 IN
Package Dimensions (L x W x H)
3.175 cm x 12.065 cm x 7.62 cm
Package Weight (Imperial)
0.450 L
Package Weight (Metric)
0.204 kg
Ground Lug

DNGL

Ground Lug
INTERLOCK UNIT,AR-12M(SEPERATE),GMC(D)-6~16M

83411621001

INTERLOCK UNIT,AR-12M(SEPERATE),GMC(D)-6~16M
ZCT,LZR-030(V),EMPR,EXP

76512124011

ZCT,LZR-030(V),EMPR,EXP
JB5-2 2 POLE JUMPER 5.2MM SPACING

1SNK905302R0000

JB5-2 2 POLE JUMPER 5.2MM SPACING
JB5-5 5 POLE JUMPER 5.2MM SPACING

1SNK905305R0000

JB5-5 5 POLE JUMPER 5.2MM SPACING
One-hole, metric conductor, standard barrel with window lug, 4-6mm wire, M8 stud hole.

LCMA6-8-C

One-hole, metric conductor, standard barrel with window lug, 4-6mm wire, M8 stud hole.

Frequently Asked Questions

What voltage rating does the THQL1115AF2 support?

The THQL1115AF2 supports a voltage rating of 120/240 Vac, making it suitable for single-phase systems.

What is the interrupting rating of the THQL1115AF2?

The THQL1115AF2 has an interrupting rating of 10,000 AIC, protecting against up to 10,000 amps of fault current.

Does the THQL1115AF2 protect against both parallel and series arcs?

Yes, the THQL1115AF2 is a Combination AFCI that protects against both parallel and series arcs, meeting NEC standards.

Is the THQL1115AF2 UL listed?

Yes, the THQL1115AF2 is UL Listed to UL 489 standards, ensuring compliance with safety and performance requirements.

What is the ampere rating of the THQL1115AF2?

The THQL1115AF2 has an ampere rating of 15 Amperes, suitable for protecting low to moderate load circuits.

What load centers are compatible with the THQL1115AF2?

The THQL1115AF2 is designed for use in ABB and GE load centers, meter combos, and modular metering systems.

Does the THQL1115AF2 include a common trip bar?

Yes, the THQL1115AF2 features a common trip bar to ensure simultaneous disconnection of both poles during a fault.

What applications is the THQL1115AF2 suitable for?

The THQL1115AF2 is ideal for residential and light commercial applications, including living rooms, bedrooms, and kitchens.
