ABB - Electrification TF96-78 - The TF96-78 thermal overload relay is an economic electromechanical protection device for the main circuit. It offers reliable and fast protection for motors in the event of overload or phase failure. The device has trip class 10. Further features are the temperature compensation, trip contact (NC), signal contact (NO), automatic- or manual reset selectable, trip-free mechanism, STOP function and a trip indication. The overload relays are connected directly to the block contactors. Single mounting kits are available as accessory.
ABB - Electrification

TF96-78

Contact for Pricing

Overview

The ABB TF96-78 (SKU: TF96-78) is an economical electromechanical thermal overload relay designed for direct main circuit protection of electric motors. This three-pole relay utilizes bimetal tripping elements that are heated by motor current, directly and indirectly. In overload conditions, the bimetal elements bend, triggering a relay release and changing the contact switching positions (95-96 / 97-98). It provides reliable and fast protection for motors against overload and phase failure, featuring a Trip Class 10 rating for rapid response. Key specifications and features include: * **Setting Range:** 65.0 to 78.0 A * **Trip Class:** 10 * **Short-Circuit Protective Device:** Requires a 200 A, gG Type Fuse * **Phase Loss Sensitivity:** Compliant with IEC/EN 60947-4-1 * **Reset Function:** Selectable manual or automatic reset * **Additional Functions:** Integrated TEST and STOP function with front-mounted trip indication * **Temperature Compensation:** Ensures consistent performance across varying temperatures * **Application Suitability:** Suitable for both three- and single-phase motor applications * **Direct Connection:** Designed for direct mounting to ABB AF80 and AF96 contactors * **ATEX Certification:** Valid for products manufactured from week 26, 2015. This electromechanical device offers a trip-free mechanism and includes a normally closed (NC) trip contact and a normally open (NO) signal contact. A single mounting kit is available as an accessory for flexible installation. Origin: US.
  • ABB TF96-78 Thermal Overload Relay
  • Setting Range: 65.0 - 78.0 A
  • Trip Class 10 for fast motor protection
  • Phase loss sensitive (IEC/EN 60947-4-1)
  • Selectable manual or automatic reset

Specifications

Ambient Air Temperature
Operation -40 ... +70 °C / Operation Compensated -40 ... +70 °C / Storage -50 ... +80 °C
Application
Mainly used for controlling 3-phase motors and generally for controlling power circuits up to 690 V AC and 220 V DC. The contactors can also be used for many other applications such as bypass, capacitor switching, lighting, DC power circuits.
Product Name
Thermal Overload Relay
Size
82x110x108mm
Special Features
The TF96-78 thermal overload relay is an economic electromechanical protection device for the main circuit. It offers reliable and fast protection for motors in the event of overload or phase failure. The device has trip class 10. Further features are the temperature compensation, trip contact (NC), signal contact (NO), automatic- or manual reset selectable, trip-free mechanism, STOP function and a trip indication. The overload relays are connected directly to the block contactors. Single mounting kits are available as accessory.
Standard
RoHs, CSA, cUL, CE, GOST
Trip Class
class 10
Type
Contactors
Voltage Rating
Auxiliary Circuit 600 V AC / DC / Main Circuit 690/440 V AC/V DC
Package Dimensions (L x W x H)
3.819 IN x 3.819 IN x 4.764 IN
Package Dimensions (L x W x H)
9.7003 cm x 9.7003 cm x 12.1006 cm
Package Weight (Imperial)
1.367 L
Package Weight (Metric)
0.620 kg
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.

1SNK705010R0000

Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.
