ABB - Electrification TF42-10 - The TF42-10 thermal overload relay is an economic electromechanical protection device for the main circuit. It offers reliable and fast protection for motors in the event of overload or phase failure. The device has trip class 10. Further features are the temperature compensation, trip contact (NC), signal contact (NO), automatic- or manual reset selectable, trip-free mechanism, STOP function and a trip indication. The overload relays are connected directly to the block contactors. Single mounting kits are available as accessory.
ABB - Electrification

TF42-10

Contact for Pricing

Overview

The ABB TF42-10 thermal overload relay (SKU: TF42-10) is a compact electromechanical protection device designed for direct connection to ABB block contactors in industrial motor control systems. Rated at 40A with Trip Class 10, it provides reliable protection against overload conditions and phase failure in 3-phase motors operating at 240VAC (10 HP), 480VAC (20 HP), or 600VAC (25 HP). The relay features integrated temperature compensation for stable performance across ambient conditions ranging from -25°C to +55°C, ensuring consistent tripping accuracy regardless of environmental fluctuations. Key specifications include a normally closed (NC) trip contact for immediate shutdown signaling and a normally open (NO) signal contact for status monitoring. Users can select between automatic or manual reset modes, with a trip-free mechanism preventing reset during fault conditions. The device also includes a dedicated STOP function and clear trip indication for rapid diagnostics. The TF42-10 is designed for direct mounting on ABB contactors (AF09 to AF370 series) and is compatible with single mounting kits for versatile installation configurations. With a weight of 0.16 kg (0.35 lb) and dimensions optimized for space-constrained panels, this relay is ideal for applications in manufacturing, HVAC systems, pumps, conveyors, and other industrial machinery where motor protection is critical. The relay meets UL508 standards (File #E63822) and offers a short-circuit rating of 5kA with RK5-type fuses. Its 4-pole configuration supports balanced load distribution, while the compact design minimizes panel space requirements. The TF42-10 is manufactured in the US, ensuring compliance with domestic industrial standards and providing a reliable solution for motor protection in demanding environments.
  • 40A rated thermal overload relay for 3-phase motors up to 25 HP (240V/480V/600V)
  • Trip Class 10 for fast protection against overload and phase failure
  • Temperature compensation (-25°C to +55°C) for stable tripping accuracy
  • NC trip contact, NO signal contact, automatic/manual reset, STOP function
  • Direct mount on ABB contactors (AF09 to AF370 series), 0.16 kg weight

Specifications

Ambient Air Temperature
Operation -25 ... +60 °C / Operation Compensated -25 ... +60 °C / Storage -50 ... +80 °C
Application
Mainly used for controlling 3-phase motors and generally for controlling power circuits up to 690 V AC and 220 V DC. The contactors can also be used for many other applications such as bypass, capacitor switching, lighting, DC power circuits.
Mounting Type
Direct mount on block contactors
Product Name
Thermal Overload Relay
Series
TF42
Size
82x110x108mm
Special Features
The TF42-10 thermal overload relay is an economic electromechanical protection device for the main circuit. It offers reliable and fast protection for motors in the event of overload or phase failure. The device has trip class 10. Further features are the temperature compensation, trip contact (NC), signal contact (NO), automatic- or manual reset selectable, trip-free mechanism, STOP function and a trip indication. The overload relays are connected directly to the block contactors. Single mounting kits are available as accessory.
Standard
RoHs, CSA, cUL, CE, GOST
Trip Class
class 10
Type
Contactors
Voltage Rating
Auxiliary Circuit 600 V AC / DC / Main Circuit 690 V AC
Package Dimensions (L x W x H)
3.071 IN x 1.89 IN x 3.622 IN
Package Dimensions (L x W x H)
7.8003 cm x 4.8006 cm x 9.1999 cm
Package Weight (Imperial)
0.350 L
Package Weight (Metric)
0.159 kg
