SUP402M-K8
Contact for Pricing
Overview
- UL 489 and CSA 22.2 No. 5 certified for branch circuit protection
- K-type tripping characteristic (8–12x In) for moderate inrush currents
- Pluggable design for quick installation/maintenance in SMISSLINE TP systems
- IP20 touch-safe housing with front-mounted status indicators
- 10kA short-circuit interrupting rating at 277/480 VAC, 50/60 Hz
- Supports auxiliary switches (S2C-H6RU/S2C-S6RU) for expanded monitoring
- 6,000 electrical operations and 20,000 mechanical operations durability
- Shock-resistant (25g) and reference tripping temperature of 40°C
- Relocatable plug contacts for flexible configuration
Specifications
Connection Type | Pluggable |
Current Rating | 8 A |
Frequency | 50/60 Hz |
IP Rating | IP20 |
Poles | 2 |
Series | SMISSLINE TP |
Special Features | Pluggable Miniature circuit-breaker for the SMISSLINE TP System acc. UL489 in 277/480 VAC systems, Tripping characteristic K, Rated current In 8A |
Voltage Rating | 277/480 VAC |
Package Dimensions (L x W x H) | 7.17 IN x 3.86 IN x 4.13 IN |
Package Dimensions (L x W x H) | 18.2118 cm x 9.8044 cm x 10.4902 cm |
Package Weight (Imperial) | 0.530 L |
Package Weight (Metric) | 0.240 kg |
Frequently Asked Questions
What is the rated current for the ABB SUP402M-K8?
The ABB SUP402M-K8 has a rated current (In) of 8A.
What tripping characteristic does the SUP402M-K8 feature?
The SUP402M-K8 features a 'K' tripping characteristic, suitable for circuits with moderate inrush currents.
What is the voltage rating for this circuit breaker?
This circuit breaker is rated for 277/480 VAC systems.
What is the short circuit current rating (SCCR) of the SUP402M-K8?
The SUP402M-K8 has a short circuit current rating of 10kA per UL 489.
Is the ABB SUP402M-K8 compatible with the SMISSLINE TP System?
Yes, the ABB SUP402M-K8 is specifically designed for the SMISSLINE TP System.
What standards does the SUP402M-K8 meet?
The SUP402M-K8 is UL 489 listed and also approved to CSA 22.2 No. 5.
What is the protection degree of the SUP402M-K8?
The protection degree is IP20, with IP40 when used in an enclosure with a cover.
How to Install the ABB SUP402M-K8 in SMISSLINE TP Systems
Step-by-step guide to mounting and wiring the SUP402M-K8 miniature circuit breaker in SMISSLINE TP systems.
Estimated time: 15m
Tools needed:
Screwdriver (POZI 2), DIN rail mounting tool
Supplies needed:
Mounting screws, SMISSLINE TP base unit
- Prepare the mounting location
Ensure the SMISSLINE TP base unit is securely mounted to a DIN rail or panel. Verify the mounting surface is clean and free of obstructions.
- Insert the SUP402M-K8 into the base unit
Align the breaker with the base unit’s guide rails and push firmly until it clicks into place. Ensure the plug contacts are properly seated.
- Verify connection and status indicators
Check the front-mounted pole conductor indicator (green OFF/red ON) and trip position indicator (gray NO TRIP/orange TRIP) for correct alignment. Confirm the breaker is in the OFF position before energizing.
- Connect wiring to the base unit
Route phase conductors through the base unit’s terminals, ensuring proper torque (3.5 Nm) for secure connections. Use flexible or solid copper wire as specified (1–50 mm² flexible, 1–70 mm² solid).
- Test the installation
Energize the system and verify the breaker operates correctly under load. Check for proper tripping during overload or short-circuit conditions.
