Contact for Pricing
Overview
- UL 489 listed branch circuit protective device
- 4-pole configuration
- Rated current: 30A
- Interrupting capacity: 10kA
- Fast breaking time (2.3-2.5 ms)
Specifications
Amperage Rating | 30 A |
Amperage Rating, Maximum | 30 A |
Amperage Rating, Minimum | 30 A |
Application | Mainly used for controlling 3-phase motors and generally for controlling power circuits up to 690 V AC and 220 V DC. The contactors can also be used for many other applications such as bypass, capacitor switching, lighting, DC power circuits. |
Connection Type | DIN rail / Bus connection |
Current Rating | 30 A |
Mounting Type | DIN Rail |
Number of Poles | 4 |
Poles | 4P |
Series | SU204M |
Size | 82x110x108mm |
Special Features | SU204M-C30 Miniature Circuit Breaker C-Char., 10kA, 30A, 4P UL489 |
Standard | CSA 22.2 No. 5 / IEC/EN 60947-2 / UL 489 |
Trip Type | C |
Tripping Characteristic | C |
Type | Contactors |
Voltage Rating | (480Y / 277 V AC) / (96 V DC) |
Package Dimensions (L x W x H) | 7.52 IN x 4.76 IN x 3.23 IN |
Package Dimensions (L x W x H) | 19.1008 cm x 12.0904 cm x 8.2042 cm |
Package Weight (Imperial) | 2.310 L |
Package Weight (Metric) | 1.048 kg |
Frequently Asked Questions
What is the maximum voltage rating for SU204M-C30?
The SU204M-C30 operates at voltages up to 480Y/277VAC and 96VDC.
What is the voltage rating of the SU201M-Z8?
The SU201M-Z8 operates at voltages up to 480Y/277VAC and 96VDC.
Is the SU204M-C30 compatible with existing accessories?
Yes, the SU204M-C30 is fully compatible with existing UL489 System pro M compact accessories.
What is the rated breaking capacity of this circuit breaker?
The rated breaking capacity is 10 kA according to UL489 / CSA 22.2 No. 5 and 15 kA according to IEC / EN 60947-2.
What is the rated breaking capacity?
The rated breaking capacity is 10 kA according to UL489 / CSA 22.2 No. 5 and 15 kA according to IEC / EN 60947-2.
Is the SU201M-Z8 compatible with existing accessories?
Yes, the SU201M-Z8 is fully compatible with existing UL489 System pro M compact accessories.
What is the maximum current rating?
The SU201M-Z8 is certified up to In = 40 A at 480 Y / 277 V AC.
What materials are used in the housing design?
The housing design utilizes halogen-free thermoplastic, making it recyclable and reducing environmental pollution.
What safety features does the SU204M-C30 include?
The SU204M-C30 includes real contact position indication for safety and clear identification of the MCB's state.
What type of terminals does the SU204M-C30 have?
The SU204M-C30 features IP 20 finger safe terminals with cylinder lift twin terminals.
How to Install the ABB SU204M-C30 Miniature Circuit Breaker
Step-by-step guide for installing the SU204M-C30 on a DIN rail.
Estimated time: 15m
Tools needed:
Screwdriver, Wire stripper, Wire cutter
Supplies needed:
Appropriate gauge wiring, Terminal connectors (if needed)
- Prepare the DIN rail
Ensure the DIN rail is clean, level, and securely mounted in the electrical enclosure.
- Connect the wiring
Strip the ends of the conductors to the appropriate length for the terminals. Connect the incoming power to the line-side terminals and the outgoing load to the load-side terminals. Ensure proper torque is applied to the multi-function terminals.
- Mount the breaker
Align the mounting clip on the back of the SU204M-C30 with the DIN rail. Push the breaker firmly onto the rail until it clicks into place, ensuring a secure fit. Verify that the breaker is seated correctly.
- Verify connections
Double-check all wiring connections to ensure they are secure and correctly placed. Confirm that the breaker is properly seated on the DIN rail before energizing the circuit.
