Contact for Pricing
Overview
- UL 489-listed miniature circuit breaker for branch circuit protection
- 30A current rating with 10kA interrupting rating
- Fast breaking time: 2.3–2.5 ms for rapid fault response
- DIN rail mounting with finger-safe and multi-function terminals
- UL File #E212323 and E312425 certified, CE marked, manufactured in USA
Specifications
Amperage Rating | 30 A |
Amperage Rating, Maximum | 30 A |
Amperage Rating, Minimum | 30 A |
Application | Mainly used for controlling 3-phase motors and generally for controlling power circuits up to 690 V AC and 220 V DC. The contactors can also be used for many other applications such as bypass, capacitor switching, lighting, DC power circuits. |
Connection Type | Bus connection system |
Current Rating | 30 A |
Mounting Type | DIN Rail |
Number of Poles | 1 |
Poles | 1P |
Series | SU200M |
Size | 82x110x108mm |
Special Features | SU201M-C30 Miniature Circuit Breaker C-Char., 10kA, 30A, 1P UL489 |
Standard | CSA 22.2 No. 5 / IEC/EN 60947-2 / UL 489 |
Trip Type | C |
Tripping Characteristic | C |
Type | Contactors |
Voltage Rating | (277 V AC) / (48 V DC) |
Package Dimensions (L x W x H) | 4.57 IN x 0.98 IN x 3.11 IN |
Package Dimensions (L x W x H) | 11.6078 cm x 2.4892 cm x 7.8994 cm |
Package Weight (Imperial) | 0.300 L |
Package Weight (Metric) | 0.136 kg |
Frequently Asked Questions
What is the maximum voltage rating for SU201M-C30?
The SU201M-C30 can handle voltages up to 480Y/277VAC and 96VDC.
What is the voltage rating for the SU201M-C60?
The SU201M-C60 operates at voltages up to 480Y/277VAC and 96VDC.
Is the SU201M-C60 compatible with existing accessories?
Yes, it is fully compatible with existing UL489 System pro M compact accessories.
What certifications does the SU201M-C30 have?
The SU201M-C30 complies with UL489, CSA 22.2 No. 5, and carries approvals for other relevant markets.
Is the SU201M-C30 compatible with existing accessories?
Yes, the SU201M-C30 is fully compatible with existing UL489 System pro M compact accessories.
What is the rated breaking capacity of this circuit breaker?
The rated breaking capacity is 10 kA according to UL489 / CSA 22.2 No. 5 and 15 kA according to IEC / EN 60947-2.
What safety features does the SU201M-C60 include?
It includes real contact position indication for safety and clear identification of the MCB's state.
Can the SU201M-C60 be used in both AC and DC applications?
Yes, it is designed for universal use in both AC and DC applications.
What is the maximum current rating?
The SU201M-C60 is certified up to In = 40 A at 480 Y / 277 V AC.
What is the rated breaking capacity?
The rated breaking capacity is 10 kA according to UL489/CSA 22.2 No. 5 and 15 kA according to IEC/EN 60947-2.
