ABB - Electrification ST203M-C35NA - ST203M-C35NA Miniature Circuit Breaker ST203M-C35NA Miniature Circuit Breaker C-Char., 10kA, 35A, 3P, 3P+NA
ABB - Electrification

ST203M-C35NA

Contact for Pricing

Overview

The ABB ST203M-C35NA is a robust 3-pole miniature circuit breaker (MCB) engineered for dependable electrical protection across a spectrum of industrial and commercial environments. This specific model, designated ST203M-C35NA, incorporates a neutral auxiliary contact (NA), presenting a comprehensive 3P+NA configuration. Its operational characteristics are defined by a C-characteristic tripping curve. This curve is specifically designed to accommodate circuits that experience moderate inrush currents, a common trait in applications such as lighting systems, electric motors, and transformers. The ST203M-C35NA is rated for a continuous current of 35 Amperes (35A). Furthermore, it possesses a significant breaking capacity of 10 kiloamperes (10kA), ensuring its ability to safely interrupt fault currents and protect downstream equipment. As a component of ABB Electrification's broad and integrated product offering, the ST203M-C35NA is designed for seamless compatibility with standard electrical distribution boards and control panels, facilitating straightforward integration into existing or new installations. The inherent compact design of this MCB is a key feature, contributing to optimized space utilization within electrical enclosures and panels. The integrated neutral auxiliary contact (NA) is a critical functional element, providing essential signaling capabilities. This NA contact enables a range of advanced functionalities, including remote monitoring of the circuit breaker's status, providing clear visual indication of operational states, and facilitating seamless integration into sophisticated alarm systems. These capabilities collectively enhance operational efficiency and contribute to improved safety protocols. The ST203M-C35NA is manufactured in Switzerland (CH), a testament to its high-quality construction and adherence to stringent manufacturing processes. This MCB is compliant with relevant global electrical standards, underscoring its reliability and suitability for dependable circuit protection worldwide. The Stock Keeping Unit (SKU) for this product is ST203M-C35NA. This product is classified under the UNSPSC code 39121603.
  • 3-Pole Miniature Circuit Breaker (MCB)
  • 35A Current Rating
  • 10kA Breaking Capacity
  • C-Characteristic Tripping Curve
  • Includes Neutral Auxiliary Contact (3P+NA)

Specifications

Amperage Rating
35 A
Amperage Rating, Maximum
35 A
Amperage Rating, Minimum
35 A
Breaking Capacity
10 kA
Current Rating
35 A
Interrupt Rating
(240 V AC) 10 kA / (480Y / 277 VAC) 5 kA / (125 V DC) 10 kA
Number of Poles
3
Poles
3P+NA
Series
ST203M
Special Features
ST203M-C35NA Miniature Circuit Breaker ST203M-C35NA Miniature Circuit Breaker C-Char., 10kA, 35A, 3P, 3P+NA
Trip Type
C
Tripping Characteristic
C
Tripping Characteristic
Type C
Voltage Rating
(240 V AC) / (125 V DC)
Package Dimensions (L x W x H)
2.72 IN x 2.76 IN x 3.46 IN
Package Dimensions (L x W x H)
6.9088 cm x 7.0104 cm x 8.7884 cm
Package Weight (Imperial)
1.550 L
Package Weight (Metric)
0.703 kg
Ground Lug

DNGL

Ground Lug
INTERLOCK UNIT,AR-12M(SEPERATE),GMC(D)-6~16M

83411621001

INTERLOCK UNIT,AR-12M(SEPERATE),GMC(D)-6~16M
ZCT,LZR-030(V),EMPR,EXP

76512124011

ZCT,LZR-030(V),EMPR,EXP
JB5-2 2 POLE JUMPER 5.2MM SPACING

1SNK905302R0000

JB5-2 2 POLE JUMPER 5.2MM SPACING
JB5-5 5 POLE JUMPER 5.2MM SPACING

1SNK905305R0000

JB5-5 5 POLE JUMPER 5.2MM SPACING
One-hole, metric conductor, standard barrel with window lug, 4-6mm wire, M8 stud hole.

LCMA6-8-C

One-hole, metric conductor, standard barrel with window lug, 4-6mm wire, M8 stud hole.

Frequently Asked Questions

What is the breaking capacity of this MCB?

The breaking capacity is 10kA, providing substantial protection against fault currents in industrial and commercial applications.

Does the ST203M-C35NA include an auxiliary contact?

Yes, the 3P+NA configuration includes a neutral auxiliary contact for integrated signaling or control functions.

What is the current rating of the ST203M-C35NA?

The current rating is 35A, as specified for this miniature circuit breaker model.

What is the UNSPSC code for this product?

The UNSPSC code for the ST203M-C35NA is 39121603, classifying it as a miniature circuit breaker.

Where is the ST203M-C35NA manufactured?

The ST203M-C35NA is manufactured in Switzerland (CH).

What is the tripping characteristic of the ST203M-C35NA?

The ST203M-C35NA features a C-characteristic tripping curve, designed for circuits with moderate inrush currents such as lighting and motors.

Is the ST203M-C35NA compatible with standard DIN rails?

Yes, the ST203M-C35NA is designed for installation on standard DIN rails in distribution boards.

What applications is this MCB suitable for?

The ST203M-C35NA is suitable for lighting systems, motors, transformers, and other circuits with moderate inrush currents.
