SPHDOS20

The ABB SPHDOS20 substructure is designed for ABB Power Break™ II breakers, specifically the Hi-Break rated drawout type.

The SPHDOS20 substructure has an OS20 frame rating and a capacity of 800 Amps.

No, substructure secondary disconnects for the SPHDOS20 are ordered and priced separately.

The SPHDOS20 substructure features holes for bolting on shelves or supports, and holes in the primary stabs for bolting to busbars or terminal lugs.

The SPHDOS20 is a Hi-Break rated substructure and should be used with Power Break™ II Hi-Break breakers.
