ABB - Electrification
S204MUC-Z63
Contact for Pricing
Overview
- 4-pole miniature circuit breaker (MCB)
- Rated current (In) of 0.5A
- Part of the System pro M compact® series
- DIN rail mounting type
- 6kA breaking capacity (Icn)
Specifications
Amperage Rating | 63 A |
Amperage Rating, Maximum | 63 A |
Amperage Rating, Minimum | 63 A |
Application | Mainly used for controlling 3-phase motors and generally for controlling power circuits up to 690 V AC and 220 V DC. The contactors can also be used for many other applications such as bypass, capacitor switching, lighting, DC power circuits. |
Interrupt Rating | (500 V DC) 10 kA / (480Y / 277 V AC) 6 kA |
Number of Poles | 4 |
Size | 82x110x108mm |
Special Features | The miniature circuit breaker S 200 M UC extends the establishedABB System pro M compact® product range with an MCB for DC and AC applications. The S 200 M UC impresses with its performance range and the accordingly large amount of approvals. Its high inbuilt short circuit breaking capacity across theentire model line, its flexible AC and DC application and its approval and compliance in accordance with all major international and local standards make it truly unique.All current System pro M compact® accessories can be combined easily with the new model line. Whether warehousing or project engineering, planning, installing or maintaining your equipment, the S 200 M UC is a simple and flexible solution. |
Standard | CSA 22.2 No. 235 / IEC/EN 60947-2 / UL 1077 |
Trip Type | Z |
Tripping Characteristic | Z |
Type | Contactors |
Voltage Rating | (500 V DC) / (480Y / 277 V AC) |
Package Dimensions (L x W x H) | 3.58 IN x 3.62 IN x 3.15 IN |
Package Dimensions (L x W x H) | 9.0932 cm x 9.1948 cm x 8.001 cm |
Package Weight (Imperial) | 1.200 L |
Package Weight (Metric) | 0.544 kg |
Frequently Asked Questions
What is the rated current of the ABB S204MUC-Z63?
The ABB S204MUC-Z63 has a rated current (In) of 0.5A.
How many poles does the S204MUC-Z63 have?
The ABB S204MUC-Z63 is a 4-pole miniature circuit breaker.
What mounting type does the S204MUC-Z63 use?
The ABB S204MUC-Z63 is designed for DIN rail mounting.
What is the breaking capacity of this ABB MCB?
The S204MUC-Z63 has a breaking capacity (Icn) of 6kA.
Is the S204MUC-Z63 compatible with System pro M compact® accessories?
Yes, all current System pro M compact® accessories can be combined easily with the S200 M UC model line, including the S204MUC-Z63.
