ABB - Electrification S204MUC-K0.3 - All current System pro M compact® accessories can be combined easily with the new model line. Whether warehousing or project engineering, planning, installing or maintaining your equipment, the S 200 M UC is a simple and flexible solution.
ABB - Electrification

S204MUC-K0.3

Contact for Pricing

Overview

The ABB S204MUC-K0.3 is a 4-pole miniature circuit breaker from the System pro M compact® series, featuring a rated current of 0.3A. This device is designed for flexible integration within electrical installations, offering compatibility with all current System pro M compact® accessories. Whether for warehousing, project engineering, installation, or maintenance, the S200 M UC series provides a simple and adaptable solution. The S204MUC-K0.3, with its 4 poles and 0.3A rating, is suitable for applications requiring precise overcurrent protection. ABB's commitment to interoperability ensures that this breaker works seamlessly with auxiliary contacts like the S2C-H6RU for remote status indication (ON/OFF) and the S2C-S6RU Bell Alarm Contact for tripped status alerts. For critical safety and operational control, S2C-A...U Shunt Trips (available in 12-60V AC/DC or 110-415V AC / 110-250V DC) can be integrated for remote tripping. Additionally, the S2C-DH Rotary Operating Mechanism allows for through-the-door operation, enabling the breaker to function as a main disconnecting means. This simplifies inventory and planning, making the S204MUC-K0.3 a reliable choice for enhancing circuit protection and operational efficiency in various electrical systems. Trust ABB Electrification for high-quality components.
  • ABB S204MUC-K0.3 Miniature Circuit Breaker
  • 4 Poles
  • Rated Current: 0.3A
  • System pro M compact® Series
  • Compatible with System pro M accessories

Specifications

Amperage Rating
0.3 A
Amperage Rating, Maximum
0.3 A
Amperage Rating, Minimum
0.3 A
Application
Mainly used for controlling 3-phase motors and generally for controlling power circuits up to 690 V AC and 220 V DC. The contactors can also be used for many other applications such as bypass, capacitor switching, lighting, DC power circuits.
Interrupt Rating
(500 V DC) 10 kA / (480Y / 277 V AC) 6 kA
Number of Poles
4
Size
82x110x108mm
Special Features
The miniature circuit breaker S 200 M UC extends the establishedABB System pro M compact® product range with an MCB for DC and AC applications. The S 200 M UC impresses with its performance range and the accordingly large amount of approvals. Its high inbuilt short circuit breaking capacity across theentire model line, its flexible AC and DC application and its approval and compliance in accordance with all major international and local standards make it truly unique.All current System pro M compact® accessories can be combined easily with the new model line. Whether warehousing or project engineering, planning, installing or maintaining your equipment, the S 200 M UC is a simple and flexible solution.
Standard
CSA 22.2 No. 235 / IEC/EN 60947-2 / UL 1077
Trip Type
K
Tripping Characteristic
K
Type
Contactors
Voltage Rating
(500 V DC) / (480Y / 277 V AC)
Package Dimensions (L x W x H)
2.28 IN x 3.62 IN x 3.15 IN
Package Dimensions (L x W x H)
5.7912 cm x 9.1948 cm x 8.001 cm
Package Weight (Imperial)
1.200 L
Package Weight (Metric)
0.544 kg
Ground Lug

DNGL

Ground Lug
INTERLOCK UNIT,AR-12M(SEPERATE),GMC(D)-6~16M

83411621001

INTERLOCK UNIT,AR-12M(SEPERATE),GMC(D)-6~16M
ZCT,LZR-030(V),EMPR,EXP

76512124011

ZCT,LZR-030(V),EMPR,EXP
JB5-2 2 POLE JUMPER 5.2MM SPACING

1SNK905302R0000

JB5-2 2 POLE JUMPER 5.2MM SPACING
JB5-5 5 POLE JUMPER 5.2MM SPACING

1SNK905305R0000

JB5-5 5 POLE JUMPER 5.2MM SPACING
One-hole, metric conductor, standard barrel with window lug, 4-6mm wire, M8 stud hole.

LCMA6-8-C

One-hole, metric conductor, standard barrel with window lug, 4-6mm wire, M8 stud hole.

Frequently Asked Questions

What is the rated current of the ABB S204MUC-K0.3?

The ABB S204MUC-K0.3 has a rated current of 0.3A.

How many poles does the S204MUC-K0.3 circuit breaker have?

The S204MUC-K0.3 circuit breaker is a 4-pole device.

Is the S204MUC-K0.3 compatible with other System pro M compact accessories?

Yes, all current System pro M compact® accessories can be combined easily with the new model line, including the S204MUC-K0.3.
