ABB - Electrification S203MUC-K0.5 - All current System pro M compact® accessories can be combined easily with the new model line. Whether warehousing or project engineering, planning, installing or maintaining your equipment, the S 200 M UC is a simple and flexible solution.
ABB - Electrification

S203MUC-K0.5

Contact for Pricing

Overview

The ABB S203MUC-K0.5 is a 3-pole miniature circuit breaker (MCB) accessory from the System pro M compact® range, featuring a rated current of 0.5A. This model line is designed for straightforward integration with all current System pro M compact® accessories, simplifying warehousing, project engineering, installation, and maintenance processes. The S200 M UC series offers a flexible and simple solution for electrical installations, ensuring efficient operations throughout the equipment lifecycle. Its compatibility allows for the utilization of existing components, which streamlines planning and reduces inventory complexity. Manufactured in the US, this accessory exemplifies ABB's commitment to providing reliable and user-friendly solutions for modern electrical infrastructure. Whether for new system designs or upgrades, the S200 M UC provides a dependable and uncomplicated path to achieving project objectives. Experience ease of integration and the assurance of ABB's quality and innovation. The S203MUC-K0.5 is a key component for building efficient and maintainable electrical systems. Key specifications include: Number of poles: 3, Rated current (I_n): 0.5A. UNSPSC Code: 39121603. All current System pro M compact® accessories can be combined easily with the new model line. Whether warehousing or project engineering, planning, installing or maintaining your equipment, the S200 M UC is a simple and flexible solution.
  • 3-pole configuration for versatile circuit protection.
  • Rated current of 0.5A for specific load requirements.
  • Part of the System pro M compact® accessory range for easy integration.
  • Simplifies warehousing, project engineering, installation, and maintenance.
  • Manufactured in the US for reliable electrical infrastructure solutions.

Specifications

Amperage Rating, Maximum
0.5 A
Amperage Rating, Minimum
0.5 A
Application
Mainly used for controlling 3-phase motors and generally for controlling power circuits up to 690 V AC and 220 V DC. The contactors can also be used for many other applications such as bypass, capacitor switching, lighting, DC power circuits.
Interrupt Rating
(500 V DC) 10 kA / (480Y / 277 V AC) 6 kA
Number of Poles
3
Size
82x110x108mm
Special Features
The miniature circuit breaker S 200 M UC extends the establishedABB System pro M compact® product range with an MCB for DC and AC applications. The S 200 M UC impresses with its performance range and the accordingly large amount of approvals. Its high inbuilt short circuit breaking capacity across theentire model line, its flexible AC and DC application and its approval and compliance in accordance with all major international and local standards make it truly unique.All current System pro M compact® accessories can be combined easily with the new model line. Whether warehousing or project engineering, planning, installing or maintaining your equipment, the S 200 M UC is a simple and flexible solution.
Standard
CSA 22.2 No. 235 / IEC/EN 60947-2 / UL 1077
Tripping Characteristic
K
Type
Contactors
Voltage Rating
(500 V DC) / (480Y / 277 V AC)
Package Dimensions (L x W x H)
2.28 IN x 3.62 IN x 3.15 IN
Package Dimensions (L x W x H)
5.7912 cm x 9.1948 cm x 8.001 cm
Package Weight (Imperial)
1.680 L
Package Weight (Metric)
0.762 kg
Ground Lug

DNGL

Ground Lug
INTERLOCK UNIT,AR-12M(SEPERATE),GMC(D)-6~16M

83411621001

INTERLOCK UNIT,AR-12M(SEPERATE),GMC(D)-6~16M
ZCT,LZR-030(V),EMPR,EXP

76512124011

ZCT,LZR-030(V),EMPR,EXP
JB5-2 2 POLE JUMPER 5.2MM SPACING

1SNK905302R0000

JB5-2 2 POLE JUMPER 5.2MM SPACING
JB5-5 5 POLE JUMPER 5.2MM SPACING

1SNK905305R0000

JB5-5 5 POLE JUMPER 5.2MM SPACING
One-hole, metric conductor, standard barrel with window lug, 4-6mm wire, M8 stud hole.

LCMA6-8-C

One-hole, metric conductor, standard barrel with window lug, 4-6mm wire, M8 stud hole.

Frequently Asked Questions

What is the rated current of the ABB S203MUC-K0.5?

The ABB S203MUC-K0.5 has a rated current of 0.5A.

How many poles does the S203MUC-K0.5 have?

The ABB S203MUC-K0.5 is a 3-pole miniature circuit breaker accessory.

What product range does the S203MUC-K0.5 belong to?

The S203MUC-K0.5 belongs to the ABB System pro M compact® accessory range.

Where is the ABB S203MUC-K0.5 manufactured?

The ABB S203MUC-K0.5 is manufactured in the US.
