Contact for Pricing
Overview
- 3-pole configuration with 6A rated current for precise overcurrent protection
- UL 1077 and CSA 22.2 No. 235 certified for North American compliance
- Supports trip curves B, C, D, K, Z and voltages up to 480V AC (277/480V)
- DIN rail mount (35mm) with 18–4 AWG terminal compatibility
- IP20 protection, -40°C to 70°C operating range, 20,000 mechanical operations
Specifications
Application | Mainly used for controlling 3-phase motors and generally for controlling power circuits up to 690 V AC and 220 V DC. The contactors can also be used for many other applications such as bypass, capacitor switching, lighting, DC power circuits. |
Series | System pro M compact |
Size | 82x110x108mm |
Special Features | The miniature circuit breaker S 200 M UC extends the establishedABB System pro M compact® product range with an MCB for DC and AC applications. The S 200 M UC impresses with its performance range and the accordingly large amount of approvals. Its high inbuilt short circuit breaking capacity across theentire model line, its flexible AC and DC application and its approval and compliance in accordance with all major international and local standards make it truly unique.All current System pro M compact® accessories can be combined easily with the new model line. Whether warehousing or project engineering, planning, installing or maintaining your equipment, the S 200 M UC is a simple and flexible solution. |
Standard | RoHs, CSA, cUL, CE, GOST |
Type | Contactors |
Package Dimensions (L x W x H) | 2.28 IN x 3.62 IN x 3.15 IN |
Package Dimensions (L x W x H) | 5.7912 cm x 9.1948 cm x 8.001 cm |
Package Weight (Imperial) | 1.680 L |
Package Weight (Metric) | 0.762 kg |
Frequently Asked Questions
Is the S203MUC-B6 compatible with other System pro M compact accessories?
Yes, it is fully compatible with all current System pro M compact accessories, including auxiliary contacts, shunt trips, and lockout devices.
What certifications does the S203MUC-B6 have?
The S203MUC-B6 is certified to UL 1077 and CSA 22.2 No. 235 standards for electrical safety.
What trip curves are available for the S203MUC-B6?
The S203MUC-B6 supports trip curves B, C, D, K, and Z, allowing customization for different load types and protection needs.
What is the operating temperature range for the S203MUC-B6?
The breaker operates reliably in ambient temperatures from -40°C to 70°C.
What is the short-circuit interrupt rating of this breaker?
The S203MUC-B6 offers 10kA interrupt rating at 480Y/277V AC for currents ≤32A and 5kA for 35–63A models.
What terminal sizes does the S203MUC-B6 support?
The breaker accepts terminal sizes from 18 AWG to 4 AWG for flexible wiring options.
What is the mechanical service life of the S203MUC-B6?
The S203MUC-B6 has a mechanical service life of 20,000 operations, ensuring long-term reliability.
Can the S203MUC-B6 be used in DC applications?
Yes, it supports DC applications with rated voltages up to 60/125V DC for 1/2-pole configurations.
How to Install the ABB S203MUC-B6 Circuit Breaker
Step-by-step guide to mounting and wiring the S203MUC-B6 on a 35mm DIN rail.
Estimated time: 15m
Tools needed:
Phillips screwdriver, Wire strippers, Crimping tool (optional)
Supplies needed:
35mm DIN rail, 18–4 AWG wires, Cable ties (optional)
- Prepare the DIN rail
Ensure the 35mm DIN rail is securely mounted in the panel and free of obstructions.
- Mount the breaker
Align the S203MUC-B6 with the DIN rail and snap it into place until it clicks securely.
- Connect the wires
Strip 7–10mm of insulation from the wires, insert them into the terminal screws, and tighten to 2.5–3.0 Nm torque.
- Verify connections
Gently tug the wires to confirm they are secure. Ensure no loose strands are present.
- Test the installation
Apply power and verify the breaker operates correctly by cycling it on/off.
