ABB - Electrification
S201MUC-Z8
Contact for Pricing
Overview
- Manufacturer: ABB - Electrification
- SKU: S201MUC-Z8
- Number of poles: 1
- Rated current (I_n): 8A
- Tripping characteristic: Z-curve
Specifications
Amperage Rating | 8 A |
Amperage Rating, Maximum | 8 A |
Amperage Rating, Minimum | 8 A |
Application | Mainly used for controlling 3-phase motors and generally for controlling power circuits up to 690 V AC and 220 V DC. The contactors can also be used for many other applications such as bypass, capacitor switching, lighting, DC power circuits. |
Interrupt Rating | (250 V DC) 10 kA / (277 V AC) 6 kA |
Number of Poles | 1 |
Size | 82x110x108mm |
Special Features | The miniature circuit breaker S 200 M UC extends the establishedABB System pro M compact® product range with an MCB for DC and AC applications. The S 200 M UC impresses with its performance range and the accordingly large amount of approvals. Its high inbuilt short circuit breaking capacity across theentire model line, its flexible AC and DC application and its approval and compliance in accordance with all major international and local standards make it truly unique.All current System pro M compact® accessories can be combined easily with the new model line. Whether warehousing or project engineering, planning, installing or maintaining your equipment, the S 200 M UC is a simple and flexible solution. |
Standard | CSA 22.2 No. 235 / IEC/EN 60947-2 / UL 1077 |
Trip Type | Z |
Tripping Characteristic | Z |
Type | Contactors |
Voltage Rating | (250 V DC) / (277 V AC) |
Package Dimensions (L x W x H) | 2.28 IN x 3.62 IN x 3.15 IN |
Package Dimensions (L x W x H) | 5.7912 cm x 9.1948 cm x 8.001 cm |
Package Weight (Imperial) | 2.870 L |
Package Weight (Metric) | 1.302 kg |
Frequently Asked Questions
What is the rated current of the ABB S201MUC-Z8?
The ABB S201MUC-Z8 has a rated current of 8A.
How many poles does the S201MUC-Z8 MCB have?
The ABB S201MUC-Z8 is a 1-pole Miniature Circuit Breaker.
What type of tripping characteristic does the S201MUC-Z8 feature?
The ABB S201MUC-Z8 features a Z-curve tripping characteristic.
Is the S201MUC-Z8 compatible with other System pro M compact accessories?
Yes, all current System pro M compact® accessories can be combined easily with the new model line, including the S201MUC-Z8.
What does 'UC' signify in the S201MUC-Z8 model name?
The 'UC' designation in the S201MUC-Z8 indicates Universal Current, signifying broad application compatibility.
