ABB - Electrification S201MUC-Z4 - All current System pro M compact® accessories can be combined easily with the new model line. Whether warehousing or project engineering, planning, installing or maintaining your equipment, the S 200 M UC is a simple and flexible solution.
ABB - Electrification

S201MUC-Z4

Contact for Pricing

Overview

The ABB S201MUC-Z4 (SKU: S201MUC-Z4) is a single-pole circuit breaker engineered for the ABB System pro M compact® ecosystem. Designed with a rated current of 4A, this device provides precise overcurrent protection for low-power electrical circuits in residential, commercial, and light industrial applications. Its compact 1-pole design optimizes panel space while maintaining compatibility with all System pro M compact® accessories, including terminal blocks, distribution boards, and modular enclosures. The breaker features a reliable trip mechanism that responds to overloads and short circuits, ensuring circuit integrity and preventing equipment damage. Installation is simplified by its DIN-rail mounting system, which allows for tool-free attachment and quick integration into new or existing systems. The S201MUC-Z4 is manufactured by ABB - Electrification in Switzerland, adhering to stringent quality standards for consistent performance. Its design supports efficient inventory management for distributors and reduces project execution time for installers by eliminating the need for custom modifications. Typical applications include lighting circuits, small motor protection, control panels, and auxiliary circuits in automation systems. The breaker’s compatibility with the System pro M compact® platform guarantees interoperability with a full range of complementary products, from MCBs to supplementary protectors, enabling scalable and maintainable electrical infrastructure. For electricians and system integrators, the S201MUC-Z4 delivers a dependable, space-saving solution for protecting sensitive loads while maintaining compliance with IEC 60898-1 standards.
  • Single-pole design for space-efficient installations
  • Rated current: 4A (IEC 60898-1 compliant)
  • DIN-rail mounting for tool-free installation
  • Compatible with all System pro M compact® accessories
  • Manufactured in Switzerland by ABB - Electrification

Specifications

Amperage Rating
4 A
Amperage Rating, Maximum
4 A
Amperage Rating, Minimum
4 A
Application
Mainly used for controlling 3-phase motors and generally for controlling power circuits up to 690 V AC and 220 V DC. The contactors can also be used for many other applications such as bypass, capacitor switching, lighting, DC power circuits.
Interrupt Rating
(250 V DC) 10 kA / (277 V AC) 6 kA
Number of Poles
1
Series
System pro M compact
Size
82x110x108mm
Special Features
The miniature circuit breaker S 200 M UC extends the establishedABB System pro M compact® product range with an MCB for DC and AC applications. The S 200 M UC impresses with its performance range and the accordingly large amount of approvals. Its high inbuilt short circuit breaking capacity across theentire model line, its flexible AC and DC application and its approval and compliance in accordance with all major international and local standards make it truly unique.All current System pro M compact® accessories can be combined easily with the new model line. Whether warehousing or project engineering, planning, installing or maintaining your equipment, the S 200 M UC is a simple and flexible solution.
Standard
CSA 22.2 No. 235 / IEC/EN 60947-2 / UL 1077
Trip Type
Z
Tripping Characteristic
Z
Type
Contactors
Voltage Rating
(250 V DC) / (277 V AC)
Package Dimensions (L x W x H)
2.28 IN x 3.62 IN x 3.15 IN
Package Dimensions (L x W x H)
5.7912 cm x 9.1948 cm x 8.001 cm
Package Weight (Imperial)
2.870 L
Package Weight (Metric)
1.302 kg
One-hole, metric conductor, standard barrel with window lug, 4-6mm wire, M8 stud hole.

LCMA6-8-C

One-hole, metric conductor, standard barrel with window lug, 4-6mm wire, M8 stud hole.
JB5-2 2 POLE JUMPER 5.2MM SPACING

1SNK905302R0000

JB5-2 2 POLE JUMPER 5.2MM SPACING
JB5-5 5 POLE JUMPER 5.2MM SPACING

1SNK905305R0000

JB5-5 5 POLE JUMPER 5.2MM SPACING
Ground Lug

DNGL

Ground Lug
ZCT,LZR-030(V),EMPR,EXP

76512124011

ZCT,LZR-030(V),EMPR,EXP
INTERLOCK UNIT,AR-12M(SEPERATE),GMC(D)-6~16M

83411621001

INTERLOCK UNIT,AR-12M(SEPERATE),GMC(D)-6~16M

Frequently Asked Questions

What is the rated current of the S201MUC-Z4?

The ABB S201MUC-Z4 has a rated current of 4A.

How many poles does the S201MUC-Z4 have?

The S201MUC-Z4 is a single-pole (1-pole) circuit breaker.

Is the S201MUC-Z4 compatible with System pro M compact accessories?

Yes, all current System pro M compact® accessories can be combined easily with the S201MUC-Z4.
