Contact for Pricing
Overview
- Designed for precise elevator automation
- Integrated surge protection (Varistor + RC)
- Rated for IEC AC-1 operational currents up to 690V
- Meets UL/CSA general use standards
- Available with 230V AC or 24V DC input voltage
Specifications
Application | Mainly used for controlling 3-phase motors and generally for controlling power circuits up to 690 V AC and 220 V DC. The contactors can also be used for many other applications such as bypass, capacitor switching, lighting, DC power circuits. |
Size | 82x110x108mm |
Special Features | Terminal type: Screw terminals |
Standard | RoHs, CSA, cUL, CE, GOST |
Type | Contactors |
Package Dimensions (L x W x H) | 4.92 IN x 2.17 IN x 10.43 IN |
Package Dimensions (L x W x H) | 12.4968 cm x 5.5118 cm x 26.4922 cm |
Package Weight (Imperial) | 0.990 L |
Package Weight (Metric) | 0.449 kg |
ZMS132-3L
The ZLS132-3L is a combi module L1,L2,L3 top feed for the SMISSLINE TP 125A and 250A system
