Overview
- 3-pole DC-operated mini contactor with 1 auxiliary contact
- Rated for 20 A / 690 V (AC-1) and 4 kW (AC-3) at 400 V
- Flat pin connector for quick, secure plug-in wiring
- Low coil consumption (3.5 W) for direct PLC control
- Hum-free coil and switch position indicator for reliable operation
Specifications
Application | Mainly used for controlling 3-phase motors and generally for controlling power circuits up to 690 V AC and 220 V DC. The contactors can also be used for many other applications such as bypass, capacitor switching, lighting, DC power circuits. |
Connection Type | Flat Pin Connector |
Current Rating | 20 A |
Mounting Type | Rail or Wall Mounting |
Mounting Type | DIN Rail, Wall |
Poles | 3P |
Rated Control Circuit Voltage | 24 V DC |
Series | BC6-30-10 |
Series | BC6 |
Size | 82x110x108mm |
Special Features | The BC6-30-10-F mini contactor is a compact 3 pole contactor with 1 auxiliary contact and flat pin connector. They are ideally suited for applications where reliability is a must and space is at a premium. Mini contactors are used in residential buldings, commercial buildings and industrial applications for the control of single or three-phase loads up to 4 kW (AC-3) and 20 A / 690 V (AC-1) or switching of control signals. Due to the low coil consumption, this device can be directly controlled by a PLC. Further features are the noiseless and hum-free coil, a switch position indication and the integrated possibility for rail or wall mounting. |
Standard | RoHs, CSA, cUL, CE, GOST |
Terminal Type | Flat-Pin Connections |
Type | Contactors |
Voltage Rating | 690 V |
Voltage Rating | 690 V AC |
Package Dimensions (L x W x H) | 11.024 IN x 4.528 IN x 2.126 IN |
Package Dimensions (L x W x H) | 28.001 cm x 11.5011 cm x 5.4 cm |
Package Weight (Imperial) | 3.902 L |
Package Weight (Metric) | 1.770 kg |
Frequently Asked Questions
What is the coil power consumption of the BC6-30-10-F?
The coil power consumption is 3.5 W at both pull-in and holding, ensuring energy efficiency and compatibility with low-power control systems.
What is the rated operational power for the BC6-30-10-F?
The BC6-30-10-F supports a rated operational power of 4 kW under AC-3 duty at 400 V and handles 20 A / 690 V in AC-1 applications.
What are the mounting options for the BC6-30-10-F?
The BC6-30-10-F supports both DIN rail and wall mounting, providing installation flexibility for various applications.
What is the maximum voltage rating for the BC6-30-10-F?
The BC6-30-10-F is rated for up to 690 V AC, suitable for resistive or motor loads in industrial applications.
Can the BC6-30-10-F be controlled directly by a PLC?
Yes, the BC6-30-10-F features a low coil consumption of 3.5 W, making it suitable for direct control by PLC outputs.
Does the BC6-30-10-F have a switch position indicator?
Yes, the BC6-30-10-F includes an integrated switch position indication for clear operational visibility.
What is the coil voltage for the BC6-30-10-F?
The BC6-30-10-F is a DC-operated contactor with coil voltages available in ranges such as 24V, 48V, 110-125V, and 220-240V.
Is the BC6-30-10-F compliant with specific safety standards?
Yes, the contacts configuration 30-01 meets the mirror contact requirements per IEC/EN 60947-4-1 Annex F for enhanced safety.
How to Install the ABB BC6-30-10-F Mini Contactor
Step-by-step guide to mounting and wiring the BC6-30-10-F mini contactor for reliable operation.
Estimated time: 15m
Tools needed:
Screwdriver, Wire strippers, Crimping tool
Supplies needed:
Mounting screws, Flat pin connectors, Control wiring
- Prepare the mounting surface
Ensure the DIN rail or wall surface is clean and free of obstructions. For DIN rail mounting, align the contactor's rail clip with the top edge of the rail.
- Mount the contactor
Secure the BC6-30-10-F to the DIN rail by pressing firmly until it clicks into place, or mount to a wall using the provided screws through the designated holes.
- Connect the flat pin wiring
Insert the flat pin connectors into the contactor's terminals, ensuring a secure and shake-proof connection. Verify that the wiring matches the control circuit voltage (e.g., 24V DC).
- Verify switch position indication
Check the integrated switch position indicator to confirm the contactor is in the correct state (open/closed) before energizing the coil.
- Test the installation
Apply the rated control voltage to the coil and verify the contactor operates smoothly. Inspect all connections for stability and correct alignment.
