ABB - Electrification B6-30-01-03 - The B6-30-01 mini contactor is a compact 3 pole contactor with 1 auxiliary contact and screw terminals. They are ideally suited for applications where reliability is a must and space is at a premium. Mini contactors are used in residential buldings, commercial buildings and industrial applications for the control of single or three-phase loads up to 4 kW (AC-3) and 20 A / 690 V (AC-1) or switching of control signals. Further features are the silent coil, a switch position indication and the integrated possibility for rail or wall mounting.
ABB - Electrification

B6-30-01-03

Contact for Pricing

Overview

The ABB B6-30-01-03 mini contactor (SKU: B6-30-01-03) is a compact, 3-pole, electrically held contactor designed for reliable control of single and three-phase loads. It features 3 normally open (NO) power poles and 1 auxiliary contact, suitable for switching control signals or loads up to 4 kW (AC-3) and 20 A / 690 V (AC-1). This contactor is ideal for space-constrained applications in residential, commercial, and industrial settings, such as HVAC systems, lighting controls, and motor management. Key features include a silent coil for reduced noise, an integrated switch position indicator for clear operational status, and versatile mounting options. The B6-30-01-03 can be mounted directly on a standard DIN rail or via wall mounting. Electrical connections are made using secure screw terminals, ensuring durable and stable connections even in demanding environments. Manufactured by ABB - Electrification in the US, this mini contactor exemplifies precision and dependability. Its design prioritizes operational efficiency and minimal footprint, making it a practical choice where panel space is at a premium. The inclusion of an auxiliary contact adds flexibility for more complex control circuits. This model is equivalent to ABB catalog numbers such as CR463L30A*A10A0 and CR463L30A*A10AA, featuring 3 NO power poles. The contactor is rated for AC-1 at 20 A / 690 V and AC-3 at 4 kW. Its compact design and reliable operation make it a suitable choice for control tasks where space is limited and consistent performance is essential.
  • ABB B6-30-01-03 Mini Contactor
  • 3-Pole, 3 Normally Open (NO) Power Poles
  • 1 Auxiliary Contact
  • Rated 20 A / 690 V (AC-1), 4 kW (AC-3)
  • Screw Terminals, DIN Rail / Wall Mount

Specifications

Application
Mainly used for controlling 3-phase motors and generally for controlling power circuits up to 690 V AC and 220 V DC. The contactors can also be used for many other applications such as bypass, capacitor switching, lighting, DC power circuits.
Connection Type
Screw Terminals
Connection Type
Screw Terminal
Current Rating
20 A
Mounting Type
DIN Rail / Wall Mount
Mounting Type
Rail or Wall Mounting
Poles
3
Poles
3P
Rated Control Circuit Voltage
48 V AC
Series
B6
Series
B6-30-01
Size
82x110x108mm
Special Features
The B6-30-01 mini contactor is a compact 3 pole contactor with 1 auxiliary contact and screw terminals. They are ideally suited for applications where reliability is a must and space is at a premium. Mini contactors are used in residential buldings, commercial buildings and industrial applications for the control of single or three-phase loads up to 4 kW (AC-3) and 20 A / 690 V (AC-1) or switching of control signals. Further features are the silent coil, a switch position indication and the integrated possibility for rail or wall mounting.
Standard
RoHs, CSA, cUL, CE, GOST
Terminal Type
Screw Terminals
Type
Contactors
Voltage Rating
690 V
Package Dimensions (L x W x H)
11.024 IN x 4.528 IN x 2.126 IN
Package Dimensions (L x W x H)
28.001 cm x 11.5011 cm x 5.4 cm
Package Weight (Imperial)
4.012 L
Package Weight (Metric)
1.820 kg
