ABB - Electrification AF26Z-30-00K-20 - AF26Z..K 3-pole contactors are used for controlling power circuits up to 690 V AC and 220 V DC. They are mainly used for controlling 3-phase motors, non-inductive or slightly inductive loads. AF..Z contactors include an electronic coil interface accepting a wide control voltage Uc min. ... Uc max. Only four coils cover control voltages between 24...250 V 50/60 Hz or 12...250 V DC. AF..Z contactors can manage large control voltage variations. One coil can be used for different control voltages used worldwide without any coil change. AF..Z contactors allow direct control by PLC-output ≥ 24 V DC 500 mA and obtain a reduced holding coil consumption. AF..Z contactors withstand short voltage dips and voltage sags (SEMI F47-0706 compliance) between 24...250 V 50/60 Hz. AF..Z contactors have built-in surge protection and do not require additional surge suppressors. Only AF..Z..-20 contactors need to respect the polarity on the coil terminals (A1+ and A2-). AF26Z..K include Push-in Spring terminals. Only one push is all you need for extremely fast wiring: faster than ever installation, easier than ever wiring, reliable as ever connections. The AF... series 1-stack 3-pole contactors are of the block type design. - Main poles and auxiliary contact blocks: 3 main poles, front and side-mounted add-on auxiliary contact blocks. (mechanically-linked auxiliary contacts compliant with Annex L of IEC 60947-5-1. N.C. mirror contacts compliant with Annex F of IEC 60947-4-1) - Accessories: a wide range of accessories is available.
ABB - Electrification

AF26Z-30-00K-20

Contact for Pricing

Overview

The ABB AF26Z-30-00K-20 is a 3-pole contactor designed for robust control of power circuits up to 690 V AC and 220 V DC. Its primary application is the control of 3-phase motors and non-inductive or slightly inductive loads. This contactor features an advanced electronic coil interface that accepts a wide range of control voltages, from 24 V AC/DC to 250 V AC/DC, utilizing only four coil types to cover global voltage requirements without coil replacement. This broad voltage tolerance ensures reliable operation even with significant voltage fluctuations and supports direct control by PLC outputs (≥ 24 V DC, 500 mA), contributing to reduced holding coil consumption. The AF26Z series contactors offer enhanced operational stability with built-in surge protection, eliminating the need for external surge suppressors and complying with SEMI F47-0706 standards for short voltage dips and sags within the 24-250 V range. The AF26Z..-20 variants, including the AF26Z-30-00K-20, require polarity adherence on coil terminals (A1+ and A2-). Installation efficiency is paramount with the AF26Z-30-00K-20, featuring Push-in Spring terminals that enable exceptionally fast and reliable connections with a single push, significantly reducing wiring time and effort. As a block-type contactor, it includes 3 main poles and supports front and side-mounted add-on auxiliary contact blocks. Mechanically-linked auxiliary contacts are compliant with IEC 60947-5-1 Annex L, and N.C. mirror contacts comply with IEC 60947-4-1 Annex F. A comprehensive range of accessories is available for further customization. Key specifications include a general use rating of 42 A at 600 V AC and a rated operational current of 45 A for AC-1 at 40°C. SKU: AF26Z-30-00K-20. Manufacturer: ABB - Electrification. UNSPSC Code: 39121529. Country of Origin: US.
  • 3-pole contactor for power circuits up to 690 V AC and 220 V DC
  • Electronic coil interface with wide control voltage range (24-250 V AC/DC)
  • Push-in Spring terminals for fast and reliable wiring
  • Built-in surge protection compliant with SEMI F47-0706
  • General use rating: 42 A at 600 V AC; AC-1 rating: 45 A at 40°C

Specifications

Connection Type
Push-in Spring terminals
Current Rating
45 A (AC-1 at 40°C)
Frequency
50/60 Hz
Mounting Type
Block type design with front and side-mounted auxiliary contact blocks
Poles
3
Rated Control Circuit Voltage
DC Operation 12 ... 20 V
Series
AF26Z
Special Features
AF26Z..K 3-pole contactors are used for controlling power circuits up to 690 V AC and 220 V DC. They are mainly used for controlling 3-phase motors, non-inductive or slightly inductive loads. AF..Z contactors include an electronic coil interface accepting a wide control voltage Uc min. ... Uc max. Only four coils cover control voltages between 24...250 V 50/60 Hz or 12...250 V DC. AF..Z contactors can manage large control voltage variations. One coil can be used for different control voltages used worldwide without any coil change. AF..Z contactors allow direct control by PLC-output ? 24 V DC 500 mA and obtain a reduced holding coil consumption. AF..Z contactors withstand short voltage dips and voltage sags (SEMI F47-0706 compliance) between 24...250 V 50/60 Hz. AF..Z contactors have built-in surge protection and do not require additional surge suppressors. Only AF..Z..-20 contactors need to respect the polarity on the coil terminals (A1+ and A2-). AF26Z..K include Push-in Spring terminals. Only one push is all you need for extremely fast wiring: faster than ever installation, easier than ever wiring, reliable as ever connections. The AF... series 1-stack 3-pole contactors are of the block type design. - Main poles and auxiliary contact blocks: 3 main poles, front and side-mounted add-on auxiliary contact blocks. (mechanically-linked auxiliary contacts compliant with Annex L of IEC 60947-5-1. N.C. mirror contacts compliant with Annex F of IEC 60947-4-1) - Accessories: a wide range of accessories is available.
Terminal Type
Push-in Spring Terminals
Voltage Rating
690 V AC / 220 V DC
Package Dimensions (L x W x H)
3.386 IN x 3.661 IN x 1.772 IN
Package Dimensions (L x W x H)
8.6004 cm x 9.2989 cm x 4.5009 cm
Package Weight (Imperial)
0.820 L
Package Weight (Metric)
0.372 kg
