ABB - Low Voltage Drives
ACS550-U1-248A-2+K454
Alternate Item Number: 3AUA0000030513
UPC: 662348050958
Documents & Media
Contact for Pricing
Overview
The ABB ACS550-U1-248A-2+K454 is a high-performance AC drive designed for industrial applications requiring reliable motor control. With a voltage input range of 3-240V and a power rating of 100HP, this drive delivers robust performance with a 1.1 overload capacity. Featuring PROFIBUS DP communication, it ensures seamless integration into automated systems. The compact yet durable design, with dimensions of 35 x 11.9 x 15.8 inches, allows for flexible installation in wall-mounted configurations. Its Type 1/IP21 enclosure provides protection against dust and light splashing, making it suitable for harsh industrial environments. Ideal for applications in manufacturing, HVAC, and material handling, the ACS550-U1-248A-2+K454 offers advanced control features, energy efficiency, and long-term reliability.
- 100HP AC drive with 3-240V input and 248A output
- 1.1 overload capacity for demanding applications
- PROFIBUS DP communication for seamless integration
- Type 1/IP21 enclosure for dust and splash protection
- Compact wall-mounted design (35 x 11.9 x 15.8 inches)
Specifications
Control Panel | Advanced |
Current Rating | 248 A |
Frame Size | R6 |
Input Phase | 3-Phase |
IP Rating | IP21 |
Mounting Type | Wall |
NEMA Rating | Type 1 |
Options | PROFIBUS DP |
Output Current | 248 |
Output Phase | 3-Phase |
Series | ACS550 |
Size | 35 x 11.9 x 15.8 in |
UL Type | 1 |
Voltage | 240 |
Voltage Range | 208-240 |
Voltage Rating | 3-200-240 VAC |
Package Dimensions (L x W x H) | 15.8 in x 11.9 in x 35 in |
Package Dimensions (L x W x H) | 40.132 cm x 30.226 cm x 88.9 cm |
Package Weight (Imperial) | 152.000 L |
Package Weight (Metric) | 68.947 kg |
