Contact for Pricing
Minimum Qty: 25
Multiplier: 25
*Contact for lower quantities*
Overview
- 2-pole male 90-degree electrical connector
- Compact 1-foot length for installation in tight spaces
- Part of NSi Industries' Mini-Link series for precision connections
- Designed for machinery, control systems, and automation applications
- Manufactured in the US by NSi Industries
Specifications
Angle | 90 Deg |
Application | Recommended cable types for use with 3/8" Steel or Aluminum Flexible Metal Conduit. Diameter for 12/2 (.44" 0 min) to 10/3 (.61" 0 max) |
Conductor Range | 12/2 - 10/3 |
Connector Type | Duplex |
Finish | Ball burnish |
Material | Zinc Die Cast |
Number Of Conductors | 1 Cable |
Poles | 2 |
Series | Mini-Link |
Size | 3/8 IN |
Size | 1 Foot |
Special Features | HCF |
Standard | UL |
Trade Size | 3/8 IN |
Type | Connector |
Package Weight (Imperial) | 0.131 L |
Package Weight (Metric) | 0.059 kg |
Similar Products
Frequently Asked Questions
What are the dimensions of the 830-DC2 connector?
The dimensions are: A: 1-1/4", B: 1/2", C: 31/32", D: .615", E: 1-1/2".
What are the dimensions of the 830-DC2 connector?
The dimensions are: A: 1-1/4", B: 1/2", C: 31/32", D: .615", E: 1-1/2".
What is the material of the 830-DC2 connector?
The 830-DC2 connector is made of zinc die cast.
What is the material of the 830-DC2 connector?
The 830-DC2 connector is made of zinc die cast.
What conduit types are compatible with the 830-DC2?
The 830-DC2 is recommended for use with 3/8" steel or aluminum flexible metal conduit.
What conduit types are compatible with the 830-DC2?
The 830-DC2 is recommended for use with 3/8" steel or aluminum flexible metal conduit.
What certifications does the 830-DC2 have?
The 830-DC2 has certifications including UL-514B and complies with NEMA Standard FB-1.
What certifications does the 830-DC2 have?
The 830-DC2 has certifications including UL-514B and complies with NEMA Standard FB-1.
What is the recommended cable diameter range?
The recommended cable diameter range is from 0.44 inches to 0.61 inches.
What is the recommended cable diameter range?
The recommended cable diameter range is from 0.44 inches to 0.61 inches.
