Contact for Pricing
Minimum Qty: 50
Multiplier: 50
*Contact for lower quantities*
Overview
- Color-coded RED for fire alarm circuit identification
- Simplifies installation with standardized, visible marking
- Ensures compliance with NFPA 72 and fire safety standards
- Part of NSI Industries' Bridgeport line of electrical components
- US-made for reliability in commercial and industrial applications
Specifications
Angle | 180 Deg |
Application | Recommended cable types for use with Steel or Aluminum 18/2 to 12/4 (.38" - .61") AC/MC/MCI-A; HCF/HCFMCI-A |
Color | Red |
Conductor Range | 18/2 to 12/4 (.38" - .61") |
Connector Type | Fire Alarm |
Finish | Red Colored |
Material | Zinc Die Cast |
Number Of Conductors | 1 Cable |
Series | Bridgeport |
Size | 3/8 IN |
Special Features | Red Color for Fire Alarm Cable |
Standard | UL |
Temperature Rating | 105?°C |
Trade Size | 3/8 IN |
Type | Connector |
Package Weight (Imperial) | 0.069 L |
Package Weight (Metric) | 0.031 kg |
Similar Products
570-GI
Color: Green
Conductor Range: 14/2 (.38" 0 min) to 10/3 AWG (.61" 0 max)
Finish: Green Colored
570-DC2
Conductor Range: 14/2 (.38" 0 min) to 10/3 (.61" 0 max)
Finish: Ball burnish
Connector Type: U Shaped
570-DCR2
Conductor Range: 14/2 (.38" 0 min) to 10/3 (.61" 0 max)
Finish: Ball burnish
Special Features: HCF/HCFMCI-A
570-S
Conductor Range: 14/2 (.44" 0 min) to 10/2 (.66" 0 max) AC/MC/MCI-A/HCF/HCFMCIA
Finish: Zinc Plated
Material: Steel
571-SI
Conductor Range: 8/3 to 6/2 (.63" - .78") AC/MC/MCIA
Finish: Zinc Electroplated
Material: Steel
Frequently Asked Questions
What types of cables are compatible with the 570-RI?
The 570-RI is recommended for use with Steel or Aluminum 18/2 to 12/4 (.38" - .61") AC/MC/MCI-A; HCF/HCFMCI-A cables.
What material is the 570-RI made from?
The 570-RI is made from zinc die cast material.
What is the finish of the 570-RI connector?
The finish of the 570-RI connector is red colored.
