Overview
- 3-pole 277VAC contactor with integrated TurnLock photocontrol
- Handles 40A resistive, ballast, and LED loads; 30A tungsten; motors up to 3HP/7.5HP
- Instant ON and 3-5 second delay OFF to prevent false switching
- NEMA Type 3R outdoor enclosure with grey enamel finish
- Meets UL773 and ANSI C136.10 standards
- Meets UL773 and ANSI C136.10 standards
- Instant ON and 3-5 second delay OFF
- Outdoor NEMA Type 3R housing
Specifications
Action | DPST |
Application | NSI |
Contact Configuration | DPST |
Contact Rating | 277 Volt |
Current Rating | 40 A |
Enclosure | Nema 3R Outdoor |
Initiation | Contact |
Number Of Poles | 2 |
Phase | Single |
Poles | 3 |
Series | 5404A |
Size | L=4.750 - W= 5.500 - H=8.500 IN |
Special Features | 6000 Watt Contactor With 3 Prong Turn Lock Receptacle |
Standard | UL 773 |
Type | 6000 Watt Contactor With Turn Lock Photocontrol |
Voltage Rating | 277 V |
Package Dimensions (L x W x H) | 4.75 IN x 5.5 IN x 8.5 IN |
Package Dimensions (L x W x H) | 12.065 cm x 13.97 cm x 21.59 cm |
Package Weight (Imperial) | 4.294 L |
Package Weight (Metric) | 1.948 kg |
