Contact for Pricing
Overview
- IR filtered silicon sensor for human eye response
- 360 joule MOV surge protection
- UV stabilized polycarbonate housing and window
- Instant ON, 2-5 second delay OFF
- 8-year warranty, UL773 and ANSI C136.10 certified
Specifications
_Power Consumption | 1 Watt Average At 120 V |
_Sensitivity | Turn On Is 1.5fc - Off-On Ratio Is 1.5:1 Average |
_Sensor | Molded Sealed IR |
_Supply Voltage | 105-305 VAC |
Application | Local Utility-Street-Highway Lighting Control |
Enclosure | Polycarbonate |
Environmental Conditions | -40 to + 158 F |
Frequency Rating | 50-60 Hz |
Mounting | Twist Lock |
Operating Temperature | -40 to + 158 F |
Size | H=2.187 - W=3.187 IN |
Special Features | 360 Joule MOV (Metal Oxide Varistor) Surge Arrestor - Locking Prongs - Silicon Photosensor |
Standard | UL |
Timing Range | 3-5 Second Delay |
Type | Utility Grade Electronic With Fail On Mode |
Package Dimensions (L x W x H) | 3.187 IN x 3.187 IN x 2.187 IN |
Package Dimensions (L x W x H) | 8.095 cm x 8.095 cm x 5.555 cm |
Package Weight (Imperial) | 0.266 L |
Package Weight (Metric) | 0.121 kg |
