Contact for Pricing
Minimum Qty: 5
Multiplier: 5
*Contact for lower quantities*
Overview
- 1-inch steel construction for durability and corrosion resistance
- 90-degree design for efficient routing in tight spaces
- Liquid-tight sealing to prevent leaks and maintain system integrity
- UL 360 and CSA certified for hazardous locations (Class I Div. 2, Class II Div. 1 & 2, Class III Div. 1 & 2)
- Internal threading for secure, leak-proof connections in industrial piping and tubing
Specifications
Angle | 90 Deg |
Application | 90 Degree connector for use with metallic liquid tight conduit. |
Connector Type | Liquidtight |
Finish | Zinc Electroplated |
Material | Steel |
Material | Malleable Iron |
Mounting Type | 90 Degree |
Size | 1 Inch |
Size | 1 IN |
Standard | cULus |
Trade Size | 1 in |
Type | Connector |
Package Weight (Imperial) | 0.814 L |
Package Weight (Metric) | 0.369 kg |
Similar Products
472-SLTI
Temperature Rating, Maximum: 221.00000 F
Temperature Rating, Minimum: 221.00000 F
Connector Type: LiquidTight, Insulated
470-SLTI
Temperature Rating, Maximum: 221.00000 F
Temperature Rating, Minimum: 221.00000 F
Size: 1/2 IN
471-SLTI
Temperature Rating, Maximum: 221.00000 F
Temperature Rating, Minimum: 221.00000 F
Connector Type: LiquidTight, Insulated
Frequently Asked Questions
What is the trade size of the connector?
The trade size of the connector is 1 inch.
Is the connector UL certified?
Yes, the connector is UL certified under UL Standard 514B.
What is the application of the 472-SLT connector?
The connector is used for 90-degree connections with metallic liquid tight conduit.
What is the material of the connector?
The connector is made of malleable iron.
What are the dimensions of the connector?
The dimensions are A: 6/16 inches, B: 1-7/8 inches, C: 1-3/4 inches.
What is the catalog ID for the connector?
The catalog ID for the connector is 472-SLT.
What is the finish of the 472-SLT connector?
The finish of the connector is zinc electro-plate.
What is the UPC number for the product?
The UPC number for the product is 781747024725.
What certifications does the connector have?
The connector meets Federal Specification A-A-50552 and NEMA Standard FB-1.
