Contact for Pricing
Minimum Qty: 50
Multiplier: 50
*Contact for lower quantities*
Overview
- UL Listed for 14/4 to 6/3 AC/MC/MCIA cables and 3/8" trade size FMC
- Malleable iron construction with electro-zinc plating for corrosion resistance
- Thermoplastic insulator rated for 150°C (302°F) applications
- Lay-in lug design simplifies installation and reduces wire pulling effort by 50%
- Includes locknut for vibration-resistant, concrete-tight seal
Specifications
Angle | 180 Deg |
Application | For use with AC/MC/MCIA in Steel or Aluminum in sizes from 14/4 to 6/3 and FMC in 3/8" trade sizes. |
Conductor Range | 14/4 to 6/3 AC/MC/MCIA |
Connector Type | Squeeze, Insulated |
Finish | Zinc Plated |
Material | Malleable Iron - Zinc Plated |
Number Of Conductors | 1 Cable |
Size | 3/8 IN |
Special Features | NPSM Threads ROHS Compliant |
Standard | cULus |
Temperature Rating | 105?°C |
Trade Size | 3/8 IN |
Type | Connector |
Package Weight (Imperial) | 0.079 L |
Package Weight (Metric) | 0.036 kg |
Similar Products
403
Application: Used to connect flexible metal conduit to box or enclosure.
Finish: Zinc Electroplated
Material: Malleable Iron
Frequently Asked Questions
What is the trade size of the 403-I connector?
The trade size of the 403-I connector is 3/8 inches.
Is the 403-I connector UL listed?
Yes, the 403-I connector is UL listed under standard 514B.
What is the finish of the 403-I connector?
The finish of the 403-I connector is zinc plated.
What is the catalog ID for the 403-I connector?
The catalog ID for the 403-I connector is 403-I.
What materials is the 403-I connector made from?
The 403-I connector is made from malleable iron and is zinc plated.
What sizes of AC/MC/MCIA can the 403-I connector accommodate?
The connector accommodates AC/MC/MCIA sizes from 14/4 to 6/3.
What types of conduit can the 403-I connector be used with?
The 403-I connector can be used with AC, MC, MCIA, and FMC conduit.
What is the UPC number for the 403-I connector?
The UPC number for the 403-I connector is 78174710403.
What is the standard packaging quantity for the 403-I connector?
The standard packaging quantity for the 403-I connector is 500 units.
What is the Federal Specification Number for the 403-I connector?
The Federal Specification Number for the 403-I connector is A-A-50553.
