ABB - Low Voltage Drives
ACS800-37-0320-5+B055+C129+K466
Alternate Item Number: 3AUA0000196799
UPC: 662348054406
Documents & Media
Contact for Pricing
Overview
The ABB ACS800-37-0320-5 Ultra Low Harmonic Cabinet Drive is a high-performance industrial drive designed for demanding applications requiring ultra-low harmonic distortion. With a power rating of 300 HP and an output current of 361A, this drive operates efficiently within a voltage range of 380-500VAC, making it suitable for a wide range of industrial environments. The NEMA 12/IP54 enclosure ensures protection against dust and water ingress, while the floor-mounted design allows for easy installation and maintenance. Equipped with a local or remote-mounted LCD display and keypad, the drive offers intuitive control and monitoring capabilities. The integrated EtherNet adapter enables seamless connectivity for remote monitoring and control. Ideal for applications in manufacturing, oil and gas, water treatment, and other industrial sectors, the ABB ACS800 drive delivers reliable performance, energy efficiency, and reduced harmonic distortion, ensuring optimal operation of your machinery.
- 300 HP, 361A output current, 480VAC voltage with 380-500V range
- Ultra-low harmonic distortion for improved power quality
- NEMA 12/IP54 enclosure for dust and water resistance
- Local or remote-mounted LCD display and keypad for easy operation
- Integrated EtherNet adapter for remote monitoring and control
Specifications
Connection Type | 3-Phase Input, 3-Phase Output |
Current Rating | 361 A |
IP Rating | IP54 |
Mounting Type | Floor-mounted |
Nema Rating | NEMA 12 |
Nema Rating | Type 12 |
Nema Rating | NEMA 12 / UL Type 12 |
Poles | 3-Phase |
Series | ACS800 |
Size | 91.1 in x 48.4 in x 25.4 in |
Voltage Rating | 480 VAC |
